Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD16X15S
$38.37
Regular price
$45.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACD16X15S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MACD Series Double Rod Cushioned Stainless Steel Miniature Cylinders
1. Complies with in-house enterprise standards;
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
Installation note:
Requires precise lateral alignment when using dual-rod configuration.
Use PTFE-based lubricant for high-temperature applications.
Maximum side load capacity: 15N at full extension.
Recommended air dryer: -40℃ pressure dew point.
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD16X15S Double-Rod Stainless Steel Mini Cylinder with Cushion
- Model: MACD16X15S
- Type: Double-rod compact cylinder with adjustable pneumatic cushion
- Bore size: 16mm
- Stroke: 15mm (standard), customizable 5-100mm
- Material: SUS304 stainless steel body, CR12MoV piston rod
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard), G1/8 optional
- Piston speed: 50-700mm/s (cushioned)
- Mounting type: Basic (no foot), optional front flange/clevis
- Seal material: Fluororubber (FKM) for high temp resistance
- Weight: 180g ±5% (excluding accessories)
- Dimensions:
- Length: 71mm (compact length)
- Width: 30mm (cylinder body diameter)
- Height: 44mm (including rod ends)
- Rod thread: M6x1.0 (both ends)
- Protection rating: IP67 (dust/water resistant)
Ultra-compact stainless steel cylinder featuring dual symmetrical piston rods and integrated air cushioning, designed for precision bidirectional force applications in corrosive environments. The polished rod surface (Ra0.4μm) ensures smooth operation and reduced seal wear. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Semiconductor wafer handling robots
- Medical sterilization equipment actuators
- Food processing line grippers
- Photovoltaic panel alignment systems
- Underwater inspection tool positioning
Installation note:
Requires precise lateral alignment when using dual-rod configuration.
Use PTFE-based lubricant for high-temperature applications.
Maximum side load capacity: 15N at full extension.
Recommended air dryer: -40℃ pressure dew point.
| Property | Property Value |
|---|---|
| sku | MACD16X15S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 16mm |
| Stroke | <15mm> |
