Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD16X300S
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD16X300S Double-Rod Buffered Stainless Steel Mini Cylinder Specifications
- Model: MACD16X300S
- Type: Double-rod cylinder with adjustable cushioning
- Bore size: 16mm
- Stroke: 300mm
- Buffer type: Adjustable rubber cushion (both ends)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Material: Stainless steel (SUS304 barrel, hardened piston rod)
- Weight: 1.3kg (without accessories)
- Dimensions: 380mm(L) × 34mm(W) × 34mm(H)
- Cushion adjustment: ±20% stroke adjustment via screw
- Mounting style: Basic foot mount (MF1) standard
- Protection rating: IP67 (wipers included)
Precision-engineered corrosion-resistant cylinder featuring synchronized dual-rod movement and progressive cushioning control. The stainless steel construction ensures exceptional durability in humid or chemically aggressive environments. Integrated magnetizable piston allows for position sensing compatibility.
- Food processing equipment (FDA-compliant lubrication options)
- Cleanroom automation in semiconductor manufacturing
- Pharmaceutical tablet pressing mechanisms
- Marine environment actuation systems
- High-temperature packaging lines
Maintenance note:
Lubricate with ISO VG32 hydraulic oil through air supply. Avoid lateral
loads exceeding 15N. For maximum lifespan, maintain operating pressure
above 0.3 MPa during high-speed cycling (≥500mm/s).
| Property | Property Value |
|---|---|
| sku | MACD16X300S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 16mm |
| Stroke | 300mm |
