Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD16X40S
$39.77
Regular price
$47.27
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACD16X40S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MACD Series Double Rod Cushioned Stainless Steel Miniature Cylinders
1. Complies with in-house enterprise standards;
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
Installation best practices:
Align rods within 0.05mm perpendicular tolerance. Use ISO VG32 turbine oil for maintenance.
Avoid side-load forces exceeding 15N. Cushion adjustment requires 50+ test cycles for optimization.
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD16X40S Double-Rod Buffered Stainless Steel Mini Cylinder Specifications
- Model: MACD16X40S
- Bore size: 16mm
- Stroke: 40mm
- Structure: Double-rod with adjustable cushioning (both ends)
- Cylinder material: Stainless steel (SUS304 barrel, chrome-plated piston rod)
- Operating pressure: 0.15–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Mounting type: Basic front flange (MF1), other options available
- Cushion adjustment: 5-stage adjustable (via screwdriver)
- Weight: 0.48kg (without accessories)
- Dimensions:
- Total length (L): 115mm (at mid-stroke)
- Body width (W): 34mm
- Height (H): 28mm (excluding mounting hardware)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Piston speed: 50–800 mm/s (cushioned)
- Lubrication: Pre-lubricated (relubrication interval: 2,000km travel distance)
High-precision stainless steel mini cylinder featuring symmetrical force output through dual rods, designed for corrosive environments requiring precise linear motion. The integrated shock-absorbing mechanism reduces end-impact noise by 65% compared to standard models. Hermetically sealed with IP67 protection against particulate/water ingress.
Ideal Applications:
- Food processing machinery (washdown environments)
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing equipment
- High-cycle automation: 24/7 operation capable
- Cleanroom manufacturing systems (ISO Class 5-8)
Installation best practices:
Align rods within 0.05mm perpendicular tolerance. Use ISO VG32 turbine oil for maintenance.
Avoid side-load forces exceeding 15N. Cushion adjustment requires 50+ test cycles for optimization.
| Property | Property Value |
|---|---|
| sku | MACD16X40S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 16mm |
| Stroke | <40mm> |
