Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD16X60S
$40.91
Regular price
$48.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACD16X60S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MACD Series Double Rod Cushioned Stainless Steel Miniature Cylinders
1. Complies with in-house enterprise standards;
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
Installation tip:
Use PTFE-based lubricant for high-temperature applications. For vertical mounting,
install rod end down to prevent contamination accumulation. Maintain 0.3–0.5mm
alignment tolerance during mechanical coupling.
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD Double Rod Cushioned Stainless Steel Mini Cylinder MACD16X60S Specifications
- Model: MACD16X60S
- Type: Double rod cylinder with adjustable pneumatic cushioning
- Bore size: 16mm
- Stroke: 60mm (±1mm tolerance)
- Material: Stainless steel (SUS304 barrel, hardened piston rod)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 150℃
- Cushioning type: Adjustable buffer at both ends
- Port size: M5×0.8 (standard) with NPT1/8 adaptor option
- Piston speed: 50–700 mm/s (lubricated)
- Seal material: Heat-resistant NBR + wear-resistant PU
- Rod end thread: M6×1.0 internal thread (both ends)
- Weight: 298g ±5g (excluding accessories)
- Dimensions:
- Length: 138mm (fully retracted)
- Width: 28mm (cylinder body diameter)
- Height: 44mm (including mounting brackets)
- ISO standard: 6432 compliant (compact series)
High-precision mini cylinder featuring corrosion-resistant stainless steel construction and dual cushioning mechanism. The through-rod design ensures symmetrical force distribution, while the 0.5μm surface finish on piston rods minimizes seal wear. Includes anti-rotation guide slots for precise linear motion alignment.
Typical Applications:
- Cleanroom automation in semiconductor manufacturing
- Precision positioning in optical lens assembly
- Food packaging machinery (sanitary design compliant)
- Medical device actuation systems
- Multi-axis coordinate measuring instruments
Installation tip:
Use PTFE-based lubricant for high-temperature applications. For vertical mounting,
install rod end down to prevent contamination accumulation. Maintain 0.3–0.5mm
alignment tolerance during mechanical coupling.
Cycle life:
3,000km travel distance (50mm/s operation) before seal replacement recommended.
Buffer adjustment requires 2mm hex key (included with factory packaging).
| Property | Property Value |
|---|---|
| sku | MACD16X60S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 16mm |
| Stroke | 60mm |
