Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD16X80S
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD Double Rod Mini Stainless Steel Cylinder MACD16X80S Specifications
- Model: MACD16X80S
- Type: Double rod with adjustable cushion (stainless steel)
- Bore size: 16mm
- Stroke: 80mm
- Operating pressure: 0.1–0.8 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: M5×0.8 (standard), G1/8 optional
- Rod diameter: 6mm (chrome-plated steel)
- Mounting type: Basic (no built-in mounts)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–700 mm/s
- Weight: 0.48 kg ±2%
- Dimensions: 120mm(L) × 34mm(W) × 34mm(H) (retracted state)
- Body material: SUS304 stainless steel
- Seal material: NBR + PU hybrid seals
- Corrosion resistance: IP67 equivalent (splash/oil proof)
Ultra-compact dual-action cylinder with precision cushioning mechanism, featuring full stainless steel construction for harsh environments. The twin-rod design ensures symmetrical force distribution and precise positioning. Includes anti-rotation guide for stable operation in high-cycle applications (up to 1.5 million cycles). Requires ISO 8573-1:2010 Class 3 compressed air.
- Semiconductor wafer handling robots
- Pharmaceutical capsule filling machines
- Marine equipment actuators (saltwater resistant)
- Cleanroom automation systems (low particle emission)
- Food packaging machinery (FDA-compliant seals)
- Precision optical lens positioning stages
Installation note:
Lubricate with ISO VG32 turbine oil before initial use. Maintain minimum 0.5mm
lateral clearance during mounting to prevent side load. Cushion adjustment
requires 5Nm torque limit - clockwise rotation reduces cushioning effect.
| Property | Property Value |
|---|---|
| sku | MACD16X80S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 16mm |
| Stroke | 80 mm |
