Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD20X150S
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD20X150S Double Rod Cushioned Stainless Steel Mini Cylinder Specifications
- Model: MACD20X150S
- Type: Double rod cylinder with adjustable pneumatic cushioning
- Bore size: 20mm
- Stroke: 150mm (±0.5mm tolerance)
- Cushion type: Front/Rear adjustable buffers
- Material: Stainless steel (SUS304 barrel, CR12MoV piston rod)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston rod diameter: 6mm (chrome-plated anti-corrosion treatment)
- Mounting style: Standard MF1 front flange with mounting holes
- Protection rating: IP67 (dust/water resistant)
- Weight: ~580g (excluding accessories)
- Dimensions:
- Barrel diameter: 20mm
- Extended length: 250mm (stroke + cylinder ends)
- Compact height: 50mm (flange mounting surface to rod end)
- Width across mounting holes: 32mm
Precision mini cylinder featuring dual stainless steel rods for balanced thrust and position stability. The integrated shock absorption system reduces end-impact noise to ≤65dB(A) at 0.5MPa. Corrosion-resistant construction with ≤0.05mm/m straightness tolerance ensures reliable performance in harsh environments. Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision alignment mechanisms in semiconductor wafer handling
- Sterile environment medical device actuators
- Food processing conveyor gate controls
- Optical lens positioning systems
- Cleanroom automation equipment
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use.
For vertical mounting, install rod end downward to prevent condensate accumulation.
Adjust cushion needles gradually - overtightening may cause piston deformation.
| Property | Property Value |
|---|---|
| sku | MACD20X150S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 150mm |
