Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD20X175S
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD20X175S Double Rod Cushioned Stainless Mini Cylinder Specifications
- Model: MACD20X175S
- Type: Double rod with adjustable rubber cushion (both ends)
- Bore size: 20mm
- Stroke: 175mm
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Port thread: M5×0.8 (standard) / NPT1/8 optional
- Cushion adjustment: 5mm adjustable stroke (both sides)
- Material: Stainless steel cylinder tube (SUS304) + aluminum end caps
- Seal type: NBR wear-resistant seals
- Weight: 840g ±2%
- Dimensions: 268mm(L) × 34mm(W) × 34mm(H) (fully extended)
- Rod diameter: 6mm (double rod)
- Mounting type: Basic (accessory brackets available)
- ISO standard: 6432
Precision mini cylinder featuring dual stainless steel piston rods and built-in shock absorption, optimized for corrosive environments requiring smooth bidirectional motion. The through-rod design eliminates piston rotation and maintains position accuracy under lateral loads. Requires filtered air (5-40μm) with 1-2 drops of ISO VG32 oil per m³.
- Pharmaceutical tablet pressing machines
- Semiconductor wafer handling robots
- Food packaging line actuators
- Micro-positioning in cleanroom environments
- Precision dispensing equipment
Installation note:
Lubricate rod surfaces with silicone grease before initial use.
Allow 0.5-1mm axial play during mounting to prevent binding.
Cushion adjustment requires 2mm hex key (included).
| Property | Property Value |
|---|---|
| sku | MACD20X175S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | 175mm |
