Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD20X200S
$57.45
Regular price
$64.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACD20X200S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MACD Series Double Rod Cushioned Stainless Steel Miniature Cylinders
1. Complies with in-house enterprise standards;
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
Installation note:
Maintain parallel alignment during mounting. For vertical installations exceeding 45° angle,
use counterbalance valves. Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
Maximum side load capacity: 15N at mid-stroke.
Critical parameters:
Do not exceed 1.0MPa working pressure. Minimum operating pressure for stable movement: 0.03MPa.
Maximum piston speed: 500mm/s. Requires 5μm filtered air supply for optimal seal longevity.
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD Double Rod Cushioned Stainless Steel Mini Cylinder MACD20X200S Specifications
- Model: MACD20X200S
- Type: Double rod, cushion-ended compact cylinder
- Bore size: 20mm
- Stroke: 200mm (adjustable stroke available)
- Cushion type: Adjustable rubber buffer (both ends)
- Material: Stainless steel body (SUS304) + aluminum end caps
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Mounting style: Standard foot + axial accessory holes
- Piston rod thread: M5x0.8 (both ends)
- Weight: 0.8kg ±3%
- Dimensions: 240mm(L) × 40mm(W) × 40mm(H)
- Seal material: NBR/FKM optional
- Corrosion resistance: IP67 (standard), IP69K optional
- Lubrication: Pre-lubricated (Grease-free operation available)
A precision stainless steel mini cylinder with dual cushioning and symmetrical double-rod design, engineered for applications requiring corrosion resistance and precise linear motion. Features hardened chrome-plated piston rods (HRC45-50) and multi-layered sealing system. Compatible with vacuum applications when paired with appropriate accessories.
Typical Applications:
- Medical device actuation systems
- Food processing equipment (sanitary environments)
- Semiconductor wafer handling robots
- Pharmaceutical packaging lines
- Laboratory automation positioning stages
- Cleanroom material transfer systems
Installation note:
Maintain parallel alignment during mounting. For vertical installations exceeding 45° angle,
use counterbalance valves. Lubricate with ISO VG32 hydraulic oil if operating below -10℃.
Maximum side load capacity: 15N at mid-stroke.
Critical parameters:
Do not exceed 1.0MPa working pressure. Minimum operating pressure for stable movement: 0.03MPa.
Maximum piston speed: 500mm/s. Requires 5μm filtered air supply for optimal seal longevity.
| Property | Property Value |
|---|---|
| sku | MACD20X200S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <200mm> |
