Airtac MACD Double Rod Stainless Steel Mini Cylinder with Cushion MACD20X250S
$60.91
Regular price
$68.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MACD20X250S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MACD Series Double Rod Cushioned Stainless Steel Miniature Cylinders
1. Complies with in-house enterprise standards;
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
Installation note:
Maintain parallel alignment of dual rods during mounting. For vertical installations,
use rod-end supports to prevent side load. Cushion adjustment requires 5 full test cycles
after initial installation for optimal performance.
2. Features asymmetrical bidirectional sealing configuration on piston with compact dimensions and integrated oil reservoir functionality;
3. Integrated shock-absorbing pads on both end covers mitigate directional change impacts;
4. Multiple rear cover configurations enable enhanced mounting flexibility;
5. Riveted composite encapsulation ensures robust connection between stainless steel barrel and end covers;
6. High-precision stainless steel tubing construction delivers exceptional structural integrity and superior corrosion resistance;
7. Comprehensive sizing options and compatible mounting accessories available for customized pneumatic solutions;
8. Full-range magnetic piston configuration as standard.
Category: Double Rod Cylinders | Brand: AIRTC | Series: MACD
AirTAC MACD Series Double Rod Cushioned Stainless Steel Mini Cylinder MACD20X250S
- Model: MACD20X250S
- Type: Double rod, adjustable cushioning, stainless steel construction
- Bore size: 20mm
- Stroke: 250mm
- Operating pressure: 0.05-1.0 MPa
- Piston rod diameter: 6mm (both ends)
- Cushion type: Adjustable rubber buffers at both ends
- Mounting type: Basic (no built-in mounting features)
- Operating temperature: -20℃ to 80℃
- Seal material: Heat-resistant NBR (Nitrile Rubber)
- Body material: Stainless steel (SUS304)
- Rod material: Stainless steel (SUS304) with hard chrome plating
- Weight: 0.82kg (excluding accessories)
- Dimensions (L×W×H):
- Standard length: 343mm (minimum retracted length)
- Full stroke length: 593mm
- Body width: 32mm
- Height with rods: 44mm
- Protection rating: IP65 (standard seals)
- Lubrication: Pre-lubricated (maintenance-free operation)
Compact stainless steel cylinder with symmetrical double-rod design and precision adjustable cushioning, ideal for applications requiring equal force/torque output in both directions. Features corrosion-resistant construction and precise position control through twin rod configuration. Requires 40μm filtered air with ISO 8573-1:2010 [3:4:3] class air quality.
Typical Applications:
- Precision alignment mechanisms in semiconductor manufacturing
- Cleanroom automation systems (pharmaceutical/food processing)
- Corrosive environment operations (chemical plants, marine applications)
- Medical device actuation systems
- Bidirectional clamping fixtures in CNC machining
Installation note:
Maintain parallel alignment of dual rods during mounting. For vertical installations,
use rod-end supports to prevent side load. Cushion adjustment requires 5 full test cycles
after initial installation for optimal performance.
| Property | Property Value |
|---|---|
| sku | MACD20X250S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | <20mm> |
| Stroke | <250MM> → <250mm> |
