Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X125-50S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Features specially profiled bi-directional sealing rings with compact dimensions and integrated oil reservoir features;
3. Front/rear covers equipped with fixed shock-absorbing pads to minimize directional switching impacts;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped joining technology ensures reliable connection between stainless steel barrel and end covers;
6. Constructed with high-precision stainless steel tubing for exceptional strength and corrosion resistance;
7. Available in multiple bore sizes with compatible mounting accessories for diversified applications;
8. Full-range magnetic piston configuration as standard.
Category: Adjustable Cylinders | Brand: Airtac | Series: MAJ
AirTAC MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X125-50S
- Model: MAJ25X125-50S
- Type: Double rod, adjustable cushion stainless steel cylinder
- Bore size: Ø25mm
- Stroke: 125mm (customizable 1-300mm)
- Rod diameter: Ø10mm (both ends)
- Operating pressure: 0.15-0.8 MPa
- Material: SUS304 stainless steel body, chrome-plated piston rod
- Mounting style: 50mm center distance base mounting (ISO 15552 standard)
- Cushion type: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃
- Seal material: Heat-resistant NBR (optionally available with FKM seals for high temp)
- Weight: 1.85kg (with mounting base)
- Dimensions:
- Total length (L): 238mm (stroke 125 + 113mm base length)
- Body width (W): 54mm
- Height (H): 58mm (including mounting base)
- Port size: M5x0.8 (standard) with G1/8 adapter optional
- Corrosion resistance: Salt spray test passed 96hrs (NSS)
Precision-engineered stainless steel cylinder with dual rod configuration for symmetrical force output in both directions. Features micrometer-style adjustable cushions (±5mm range) for precise end position tuning. The full stainless construction eliminates rust risks in washdown environments while maintaining 0.05mm repeat positioning accuracy. Integrated mounting slots allow ±2mm position adjustment during installation.
- Food packaging machinery (FDA-compliant operation)
- Pharmaceutical tablet press machines
- Cleanroom automation systems (ISO Class 5-8 environments)
- Semiconductor wafer handling robots
- Marine equipment actuators
- Precision clamping fixtures with dual-side force requirement
Maintenance tip:
Lubricate with ISO VG32 turbine oil or equivalent monthly in continuous operation.
For vacuum applications (≤-70kPa), install rod seals with vacuum-rated grease.
Critical note:
Maximum side load 15N. Always use with guided rail systems when lateral forces exceed 5N
to prevent piston rod bending. Avoid using aluminum alloy fittings with stainless body
in chloride-rich environments to prevent galvanic corrosion.
| Property | Property Value |
|---|---|
| sku | MAJ25X125-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 125mm |
