Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S
The AirTAC Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S is a genuine double acting, adjustable stroke standard round-body mini air cylinder with a Ø25mm bore and 225mm stroke, 1/8" air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ25 mm
- Stroke225 mm
- Port size1/8"
- Acting typeDouble acting, adjustable stroke
- Rod threadM10×1.25
- CushionFixed anti-impact bumper pads
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S
Mechanisms that need a little positional give, not a broad sweep, suit the MAJ25X225-30S: double-acting power in both directions, plus a stop screw that trims the extend stroke anywhere within the ordered 30 mm window. This 25 mm bore generates 245.3 N of push and 206.1 N of pull at 0.5 MPa, which translates to about 12 kg of vertical lift once you keep a 2:1 margin.
Durability details matter in this size class: a high-precision stainless barrel rolled together with aluminium covers, and a carbon-steel rod hard-chrome plated to 20 um against wear and mild corrosion. Fixed bumper pads take the sting out of stroke ends - deceleration only, since adjustable cushioning belongs to the MACJ series. The onboard magnet comes as standard and supports CMSG / DMSG / EMSG switches without special ordering.
Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S Technical Specifications
| Model | Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S |
|---|---|
| Series | MAJ mini cylinder |
| Bore size | Ø25 mm |
| Stroke | 225 mm |
| Acting type | Double acting, adjustable stroke |
| Port size | 1/8" |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø25mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 245 N | 206 N |
| 0.7 MPa | 344 N | 289 N |
| Max (@1.0 MPa) | 50 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S
| MAJ | Standard round-body mini cylinder (adjustable-stroke). |
|---|---|
| 25 | Bore size in mm. |
| ×225 | Stroke length in mm. |
| -30 | Adjustable stroke window (mm the extend stroke can be shortened on site). |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S Is Used
Sorting flap
Deflects small hardware such as screws and inserts between two bins on an assembly bench, the 30 mm window setting flap over-travel.
Bench press pre-position
Holds the ram of a small arbor press just above the workpiece via the stop screw until the operator cycles the power stroke.
Leak-test clamping
Applies repeatable 245 N clamping on a leak-test fixture for brass fittings, the magnet confirming full clamp before testing starts.
Is the Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S the Right Cylinder?
Compare before committing: the 20 mm MAJ pushes 157.0 N and the 32 mm MAJ 402.2 N at 0.5 MPa, so this 245.3 N bore is the middle choice for ejection, gating and light clamping. On a 225 mm stroke keep lateral load off the rod by guiding the part externally. The 30 mm adjuster is a mechanical extension stop, not a brake - with air lost, the piston drifts, so treat holding as a valving problem. FA flange and LB foot options, I and Y knuckles, and the standard-fitted magnet (CMSG / DMSG / EMSG ready) round out the mounting and sensing picture.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Bumper models: keep speed within the rated range.
- check Installation by qualified personnel per AirTAC docs.
Airtac MAJ Double Rod Adjustable Stainless Steel Mini Cylinder MAJ25X225-30S FAQ
At 0.5 MPa, 245.3 N push and 206.1 N pull; at 0.7 MPa, 343.4 N push and 288.5 N pull; 50 kgf theoretical maximum at 1.0 MPa. Double acting, on 0.15-1.0 MPa (22-145 psi) air filtered to 40 um, speed 30-800 mm/s, 1/8" ports, 10 mm rod with M10x1.25 thread, extend stroke trimmable within the 30 mm window.
FA flange and LB foot mountings cover fixed installation, while I and Y rod knuckles absorb small misalignment at the rod end. The adjustable-stroke version has no SDB option, and the built-in magnet is fitted as standard, so CMSG, DMSG or EMSG switches can be added at any time.
