Airtac MF20-25 Stainless Steel Mini Cylinder MF20X100CMFA
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X100CMFA Stainless Steel Mini Cylinder Specifications
- Series: MF20~25 Compact Cylinder Family
- Model: MF20X100CMFA
- Bore size: 20mm (MF20)
- Stroke: 100mm
- Mounting type: Front flange (CM code)
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Cushioning: Adjustable pneumatic cushion (FA suffix)
- Material: Stainless steel (SUS304 barrel, CR-SUS piston rod)
- Seal material: NBR/FKM optional
- Weight: 0.48kg ±5% (without accessories)
- Dimensions:
- Total length: 158mm (stroke 100 + base length)
- Body diameter: 32mm (max outer dimension)
- Mounting flange: 50mm(W) × 20mm(H)
- Rod end thread: M6x1
- ISO standard: Compliant with ISO 6432 mini cylinder specifications
Ultra-compact stainless steel pneumatic cylinder with corrosion-resistant construction, designed for precision linear motion in confined spaces. Features dual-action operation with adjustable end-position damping to minimize impact. The electropolished surface finish (Ra≤0.8μm) ensures cleanroom compatibility. Requires filtered air (5-50μm) with ISO 8573-1:2010 Class 3 standard.
- Medical device actuation (IV pumps, surgical robots)
- Semiconductor wafer handling systems
- Food packaging machinery in washdown environments
- Precision optical lens positioning
- Laboratory automation equipment
Installation note:
For vertical mounting, use anti-drop locking nuts on piston rod threads.
Lubricate with ISO VG32 turbine oil if using NBR seals. Maintain 0.3MPa minimum
operating pressure for stable motion.
| Property | Property Value |
|---|---|
| sku | MF20X100CMFA |
| Rear Cover Type | Round Type |
| Mounting Type | Front Flange Mounting Plate |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
