Airtac MF20-25 Stainless Steel Mini Cylinder MF20X100SCMFA
$34.18
Regular price
$41.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF20X100SCMFA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF20~25 Stainless Steel Miniature Cylinder Series (AIRTAC)
Category: Stainless Steel Miniature Cylinders | Brand: AIRTAC | Series: MF20~25
1. Compliant with JIS industrial standards;
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
Installation notes:
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X100SCMFA Stainless Steel Mini Cylinder Specifications
- Model: MF20X100SCMFA
- Series: MF20~25 (Stainless Steel Miniature Series)
- Bore size: 20mm
- Stroke: 100mm
- Action type: Double-acting
- Operating pressure: 0.15–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard), optional NPT1/8
- Mounting type: Basic foot mounting (ISO 6432 compatible)
- Material:
- Cylinder tube: Stainless Steel (SUS304)
- Piston rod: Stainless Steel (SUS304)
- End caps: Stainless Steel (SUS304)
- Seal material: NBR/FKM optional
- Built-in magnet: Yes (for magnetic sensor attachment)
- Weight: 480g ±2% (excluding accessories)
- Dimensions:
- Total length: 178mm (stroke 100mm)
- Body diameter: 20mm
- Mounting base: 25mm(W) × 40mm(H)
- Rod end thread: M6×1.0
- IP rating: IP67 (standard sealing)
- Lubrication: Pre-lubricated (use only NDM-1 Grease for maintenance)
Corrosion-resistant stainless steel cylinder designed for precision motion control in harsh environments. Features full SUS304 construction with hardened piston rod (HRC 35-40 surface hardness). Integrated magnetic piston enables position feedback via external sensors. Optional FKM seals available for high-temperature applications up to 150℃.
Typical Applications:
- Cleanroom automation (semiconductor manufacturing)
- Food processing machinery (washdown environments)
- Medical equipment sterilization systems
- Marine actuator systems
- Pharmaceutical packaging lines
Installation notes:
- Max side load: ≤3N (use guide mechanism for radial forces)
- Air filtration: Required 5μm filter + auto-drain
- Alignment tolerance: ±0.5mm angular misalignment allowed
- Do NOT use silicone-based lubricants with FKM seals
| Property | Property Value |
|---|---|
| sku | MF20X100SCMFA |
| Rear Cover Type | Round Type |
| Mounting Type | Front Flange Mounting Plate |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
