Airtac MF20-25 Stainless Steel Mini Cylinder MF20X100SU
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X100SU Stainless Steel Mini Cylinder Technical Details
- Series: MF20~25 Compact Cylinder Series
- Full model: MF20X100SU
- Bore size: 20mm (MF20)
- Stroke: 100mm ±1.5mm tolerance
- Material: SUS304 stainless steel (body/rod), aluminum end caps
- Operating pressure: 0.05~1.0 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (standard) with NPT1/8 adaptor optional
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting type: Basic (no flange) with through-hole pattern
- Weight: 520g ±3% (without accessories)
- Dimensions: 160mm(L) × 40mm(W) × 40mm(H)
- Rod thread: M6x1.0 external thread (8mm length)
- Seal material: Heat-resistant NBR with PTFE coating
- Max speed: 500mm/s (with cushioning)
- ISO standard: 6432 compliant (compact series)
Corrosion-resistant mini cylinder optimized for harsh environments requiring frequent washdowns or chemical exposure. Features dual sealing system with wiper ring for particle protection. The magnetic piston enables position sensing compatibility. Requires 5μm filtered air and ISO VG32 turbine oil lubrication (optional oil-free operation).
- Pharmaceutical tablet press machines
- Semiconductor wafer handling robots
- Food packaging line actuators
- Marine equipment controls
- Cleanroom automation systems
Installation guidance:
Maximum side load ≤15% of thrust rating. For vertical mounting,
use counterbalance valves. Lubricate every 50km stroke distance
under normal conditions (300ppm oil mist recommended).
| Property | Property Value |
|---|---|
| sku | MF20X100SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
