Airtac MF20-25 Stainless Steel Mini Cylinder MF20X10SCA
$28.60
Regular price
$36.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MF20X10SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MF20~25 Stainless Steel Miniature Cylinder Series (AIRTAC)
Category: Stainless Steel Miniature Cylinders | Brand: AIRTAC | Series: MF20~25
1. Compliant with JIS industrial standards;
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
Installation note:
Maximum side load ≤5N. For vertical mounting, use counterbalance valves.
Lubricate through air supply (oil mist 1-2 drops/m³). Avoid rapid pressure
changes exceeding 0.5 MPa/sec.
2. Features profiled bidirectional piston sealing with compact dimensions and integrated oil retention structure;
3. Fixed cushioning pads on front/rear covers minimize directional switching impact;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped roller-clad bonding between stainless steel barrel and end covers ensures robust connectivity;
6. High-precision stainless steel barrel delivers superior strength and corrosion resistance;
7. Compact design: MF series achieves shorter overall length compared to ISO 6432 standard cylinders with equivalent bore/stroke;
8. Comprehensive product range with optional mounting accessories for diversified applications.
*Engineered for precision motion control in corrosive or space-constrained environments.*
AirTAC MF20X10SCA Stainless Steel Miniature Cylinder Specifications
- Model: MF20X10SCA (MF20~25 series)
- Type: Single-acting spring return (push type)
- Bore size: 20mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Material: Stainless steel (SUS304 body, SUS303 piston rod)
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Temperature range: -20℃ to 80℃
- Seal material: Heat-resistant NBR
- Piston speed: 50–700 mm/s
- Weight: 0.18 kg (excluding accessories)
- Dimensions: 70mm(L) × 25mm(W) × 25mm(H)
- Rod thread: M6x1.0 (external)
- Protection rating: IP67 (dust/water resistant)
- Theoretical thrust: 25.1 kgf @0.8MPa
Ultra-compact corrosion-resistant cylinder with precision-ground rod and low-friction seals. Features a space-saving design with 360° adjustable mounting slots and anti-rotation guide for stable linear motion. Requires air lubrication (ISO VG32 or equivalent) for optimal performance.
Typical Applications:
- Semiconductor wafer handling robots
- Medical device actuation in sterilization environments
- Food packaging machinery with washdown requirements
- Precision optical lens positioning systems
- Laboratory automation sample handlers
Installation note:
Maximum side load ≤5N. For vertical mounting, use counterbalance valves.
Lubricate through air supply (oil mist 1-2 drops/m³). Avoid rapid pressure
changes exceeding 0.5 MPa/sec.
| Property | Property Value |
|---|---|
| sku | MF20X10SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
