2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC25X15SCA Buffered Stainless Steel Mini Cylinder Specifications
- Model: MFC25X15SCA
- Bore size: 25mm
- Stroke: 15mm
- Cushion type: Adjustable air cushion (both ends)
- Material: Stainless steel cylinder tube & end caps
- Seal material: NBR/FKM optional
- Operating pressure: 0.15-0.8 MPa
- Temperature range: -20℃ to 80℃
- Port size: PT1/8 (M5 optional)
- Piston speed: 50-700 mm/s
- Mounting types: Basic type (MFB), front flange (MFF)
- Protection rating: IP67
- Weight: 0.45 kg (standard configuration)
- Dimensions: 145mm(L) × 25mm(W) × 25mm(H) (extended length)
- Rod thread: M6×1.0
- Cushion adjustment: 2.5 turns max (both sides)
Compact stainless steel cylinder with precision buffering mechanism, featuring corrosion-resistant construction for harsh environments. The dual adjustable cushioning reduces impact noise and vibration at stroke ends, while the anodized rod enhances wear resistance. Compatible with ISO 6432 mounting accessories.
- Medical device actuation systems
- Semiconductor manufacturing equipment
- Food processing machinery (cleanroom compatible)
- Precision optical component positioning
- Laboratory automation stages


Property | Property Value |
---|---|
sku | MFC25X15SCA |
Rear Cover Type | Swivel Type |
Mounting Type | Without Mounting Accessories |
Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
Port Size | PT1/8 |
Magnet | S-Magnetic |
Bore Diameter | <25 mm> |
Stroke | <15mm> |
