Airtac MFJ Adjustable Mini Cylinder MFJ20X10-10S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Series Adjustable Miniature Cylinder MFJ20X10-10S Specifications
- Model: MFJ20X10-10S
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 10mm (±0.5mm adjustable)
- Operating pressure: 0.15–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Cushion type: External adjustable rubber bumper
- Mounting style: Basic type (no built-in mounts)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Piston rod thread: M6x1.0 external thread
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- End covers: Aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR
- Weight: 0.25kg (excluding accessories)
- Dimensions:
- Total length: 105mm (at mid-stroke)
- Body width: 40mm
- Height with rod: 40mm
- Stroke adjustment range: ±0.5mm via locknut
Ultra-compact cylinder with precision stroke adjustment capability, featuring dual anti-rotation guides for stable linear motion. The anodized surface treatment provides corrosion resistance in humid environments. Integrated cushioning adjustment screws allow fine-tuning of end-position deceleration (adjustment range: 1/4 turn = 0.2mm cushion depth change).
- Semiconductor wafer handling robots
- Precision dispensing equipment alignment
- Optical lens positioning systems
- PCB test fixture actuation
- Medical device component assembly
Installation guidelines:
Maximum side load capacity 8N. Use with guided rail systems when lateral forces exceed 3N.
Lubricate with ISO VG32 hydraulic oil if operated below -10℃. Avoid rapid pressure changes
exceeding 0.5MPa/sec to prevent seal damage.
| Property | Property Value |
|---|---|
| sku | MFJ20X10-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
