Airtac MFJ Adjustable Mini Cylinder MFJ20X100-100S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ20X100-100S Adjustable Miniature Cylinder Specifications
- Model: MFJ20X100-100S
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Air cushion with adjustable screw (both ends)
- Piston speed: 50–700 mm/s
- Ambient temperature: -10℃ to 60℃
- Port size: M5x0.8 (standard) with optional NPT1/8 adaptor
- Rod material: Chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 480g ±2% (without accessories)
- Dimensions:
- Extended length: 195mm
- Retracted length: 95mm
- Body diameter: 28mm
- Mounting base: 32mm × 32mm
- ISO standard: 6432 (mounting dimensions compatible)
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact cylinder featuring dual adjustable pneumatic cushions for precise stroke control. The precision-machined barrel ensures ≤0.5mm lateral play during operation. Includes built-in magnet for position sensing compatibility. Special anti-rotation design maintains orientation stability in high-frequency applications (≤5Hz). Requires 5μm filtered air with ISO 8573-1:2010 class 4.4.3 purity.
- PCB handling robots in electronics assembly
- Precision dosing valves in pharmaceutical packaging
- Lens positioning systems in optical manufacturing
- Textile cutting machine actuators
- Semiconductor wafer transfer mechanisms
Installation guidance:
For vertical mounting, use model-specific support brackets (AMJ20-M4 recommended).
Lubricate with ISO VG32 turbine oil if operating below -5℃. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
