Airtac MFJ Adjustable Mini Cylinder MFJ20X100-20
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-20 Technical Details
- Model: MFJ20X100-20
- Bore size: 20mm
- Stroke: 100mm (adjustable ±20mm)
- Operating pressure: 0.15–0.8 MPa
- Medium temperature: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushion type: Adjustable rubber bumper
- Mounting style: Basic female thread (NF type)
- Rod thread: M6x1.0
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR rubber
- Weight: 280g ±5g
- Dimensions:
- Extended length: 190mm
- Retracted length: 90mm
- Body width: 32mm
- Mounting base height: 14mm
Ultra-compact cylinder featuring stepless stroke adjustment through integrated locknut mechanism. The dual-port design enables bidirectional flow control, while the chromium-plated piston rod enhances corrosion resistance. Includes built-in auto-lubrication for maintenance-free operation under ISO 8573-1 air quality standards.
- Precision positioning in SMT equipment
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Optical lens alignment systems
- 3D printer nozzle positioning mechanisms
Installation tip:
Apply 2-3Nm torque during stroke adjustment locknut tightening.
Maintain 0.5mm minimum clearance between rod end and load during
thermal expansion scenarios. Compatible with AT-1000 series sensors.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
