Airtac MFJ Adjustable Mini Cylinder MFJ20X100-30S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-30S Specifications
- Model: MFJ20X100-30S
- Bore size: 20mm
- Stroke: 100mm (±0.5mm tolerance)
- Mounting type: Side-mount with integrated adjustable cushioning
- Operation: Double-acting
- Cushioning type: Rubber bumper with adjustable needle valve
- Working pressure: 0.15–0.8 MPa (21.7–116 psi)
- Temperature range: -20℃ to 80℃ (non-freezing)
- Port size: M5 x 0.8 or 1/8" NPT optional
- Piston rod thread: M10x1.25
- Material: Aluminum alloy cylinder tube, stainless steel piston rod
- Seal material: NBR (nitrile rubber) standard
- Repeat positioning accuracy: ±0.1mm
- Max speed: 500mm/s (with cushioning engaged)
- Weight: 650g (1.43 lbs) ±3%
- Dimensions: 150mm(L) × 50mm(W) × 50mm(H) (full extension)
Ultra-compact cylinder featuring progressive cushioning adjustment via 360° rotatable needle valves. The anodized aluminum body provides corrosion resistance, while the chrome-plated piston rod ensures smooth operation. Integrated mounting slots allow direct installation without brackets. Requires ISO 8573-1:2010 Class 4 compressed air.
- Precision clamping in PCB assembly lines
- Dosing valve actuation in medical devices
- Component positioning in semiconductor handlers
- Lid closing mechanisms in packaging machines
- Optics alignment systems in laser equipment
Installation note:
Adjust cushioning screws clockwise to increase damping force. Always depressurize system before adjusting.
For vertical mounting, install rod-end down to prevent particle accumulation. Lubricate with ISO VG32 hydraulic oil
if operating below 0℃.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
