Airtac MFJ Adjustable Mini Cylinder MFJ20X100-40
$41.63
Regular price
$49.13
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFJ20X100-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS standards;
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
Operation Tip:
Achieve optimal cushioning by turning adjustment screws in 1/4 rotations while monitoring piston deceleration. Use clean dry air (ISO 8573-1 class 3.4.2) and maintain 0.3-0.5MPa pressure for smooth operation. Avoid lateral loads exceeding 15N.
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-40 Technical Details
- Model Code: MFJ20X100-40 (Series: MFJ / Bore Size: 20mm / Stroke: 100mm)
- Type: Double-acting cylinder with adjustable cushioning
- Bore Diameter: 20mm ±0.1mm
- Stroke Length: 100mm (adjustable stroke available upon request)
- Operating Pressure: 0.05-0.8 MPa (7-116 PSI)
- Cushion Type: External adjustable rubber buffers (both ends)
- Port Size: M5x0.8 (1/8" NPT optional)
- Mounting Style: Front flange mount (MFJ-40 standard pattern)
- Temperature Range: -20℃ to 80℃ (NBR seals)/ -10℃ to 60℃ (FKM seals optional)
- Material:
- Tube: Aluminum alloy hard anodized
- Piston Rod: Stainless steel (SUS304) with chrome plating
- End Caps: Die-cast aluminum
- Weight: 0.62kg ±3% (excluding accessories)
- Dimensions (L×W×H):
- Retracted Length: 146mm
- Extended Length: 246mm
- Body Width: 40mm
- Mounting Height: 20mm
- Max Speed: 500mm/s (with cushion adjustment)
- Lubrication: Pre-lubricated (Relubrication interval: 2,000km travel distance)
Ultra-compact pneumatic cylinder featuring dual-sided shock absorption adjustment for precision motion control. The MFJ20X100-40 combines anodized corrosion resistance with stainless steel rod durability, optimized for high-cycle automation systems. Integrated mounting grooves enable tool-free installation in confined spaces.
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Dispenser nozzle positioning in pharmaceutical packaging
- Precision clamping fixtures for CNC machining centers
- Sorting gate actuators in logistics conveyors
- Lens positioning systems in optical equipment
Operation Tip:
Achieve optimal cushioning by turning adjustment screws in 1/4 rotations while monitoring piston deceleration. Use clean dry air (ISO 8573-1 class 3.4.2) and maintain 0.3-0.5MPa pressure for smooth operation. Avoid lateral loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
