Airtac MFJ Adjustable Mini Cylinder MFJ20X100-40S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ20X100-40S Adjustable Miniature Cylinder Specifications
- Model: MFJ20X100-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20mm
- Stroke: 100mm (adjustable)
- Rod diameter: 8mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable rubber buffers (both ends)
- Mounting style: 40S (standard front flange with mounting holes)
- Port size: M5×0.8 (G1/8 adaptor included)
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Weight: 520g ±5g
- Dimensions: 178mm(L) × 34mm(W) × 34mm(H) (retracted)
- Max theoretical force: 31.4N @ 0.5MPa
- ISO standard: ISO 6432 (compact cylinder specification)
Ultra-compact cylinder featuring patented micro-adjustment mechanism (±3mm stroke fine-tuning) with visual position indicator. Precision-ground stainless steel rod with multi-lip seal system ensures ≤0.5mm repeat positioning accuracy. Anodized aluminum body resists chemical corrosion in industrial environments.
- PCB board clamping/fixturing in electronics assembly
- Precision valve actuation in analytical instruments
- Medical device positioning mechanisms
- Packaging machine ejector systems
- Robotic end-effector tool changers
Installation note:
For optimal performance, maintain 0.3-0.5mm alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial use. Stroke adjustment requires
2mm hex key (included). Max side load: 15N.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
