Airtac MFJ Adjustable Mini Cylinder MFJ20X100-50STC
$51.61
Regular price
$59.11
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFJ20X100-50STC
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS standards;
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
Installation note:
Maintain 0.5mm minimum clearance between piston rod and mechanical stops.
Adjust cushion screws clockwise to increase damping force. Lubricate every
500km of cumulative stroke motion in continuous operation.
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-50STC Specifications
- Model: MFJ20X100-50STC
- Bore size: 20mm
- Stroke: 100mm
- Action type: Double-acting
- Operating pressure: 0.05–0.9 MPa
- Port size: M5x0.8 (standard), G1/8 optional
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Foot-mounted (STC type)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR rubber
- Temperature range: -10℃ to 80℃
- Protection rating: IP40
- Weight: 0.85kg (including accessories)
- Dimensions: 170mm(L) × 50mm(W) × 50mm(H) (max extended length)
Ultra-compact cylinder featuring precision-machined components and adjustable cushioning mechanism for controlled stopping. The STC variant includes pre-drilled mounting holes for stable fixed-base installation. Requires 5μm filtered air and regular lubrication (ISO VG32 recommended).
Typical Applications:
- Precision positioning in SMT component placement machines
- Clamping mechanisms in semiconductor wafer handling
- Actuation systems for laboratory diagnostic equipment
- Automated cosmetic/pharmaceutical dispensing systems
- Compact conveyor stoppers in packaging lines
Installation note:
Maintain 0.5mm minimum clearance between piston rod and mechanical stops.
Adjust cushion screws clockwise to increase damping force. Lubricate every
500km of cumulative stroke motion in continuous operation.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-50STC |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
