Airtac MFJ Adjustable Mini Cylinder MFJ20X125-100S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ20X125-100S Adjustable Mini Cylinder Specifications
- Model: MFJ20X125-100S
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Standard switch base (100 series)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR rubber
- Weight: 0.52kg (without accessories)
- Dimensions (L×W×H): 200×40×40mm (full extension)
- Max theoretical thrust: 31.4kgf @0.5MPa
- Max speed: 500mm/s
- Protection rating: IP54
Ultra-compact cylinder featuring dual adjustable air cushions for precise stroke-end control. The MFJ series combines a space-saving design (25% smaller than standard cylinders) with enhanced lateral load capacity. Precision-machined guide slots enable easy sensor mounting, while the built-in cushion mechanism reduces impact noise by 60% compared to fixed cushion models.
- PCB handling robots in electronics manufacturing
- Precision dosing valves in medical devices
- Label applicators in packaging lines
- Semiconductor wafer transfer mechanisms
- Automated optical inspection (AOI) equipment
Installation tip:
For vertical mounting applications, reduce cushion adjustment by 1/4 turn to compensate for gravity acceleration.
Always maintain air filtration at 5μm or finer to preserve cushion seal integrity.
| Property | Property Value |
|---|---|
| sku | MFJ20X125-100S |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
