Airtac MFJ Adjustable Mini Cylinder MFJ20X125-20S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X125-20S Specifications
- Model: MFJ20X125-20S
- Series: MFJ (Compact Adjustable Cushion)
- Bore size: 20mm
- Stroke: 125mm
- Mounting type: Standard foot & front flange
- Operating pressure: 0.05–0.9 MPa
- Cushioning type: Adjustable (both ends)
- Port size: M5x0.8 (dual ports)
- Piston rod thread: M10x1.25
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR/PU standard (FKM optional)
- Temperature range: -10℃ to 80℃
- Protection rating: IP40
- Repeat positioning accuracy: ±0.5mm
- Max speed: 1.5 m/s
- Weight: 0.68 kg (dry)
- Dimensions:
- Extended length: 218mm
- Retracted length: 93mm
- Body width: 40mm
- Height (with rod): 52mm
A space-saving pneumatic actuator featuring dual adjustable rubber cushions for precise end-position control. The MFJ series combines compact dimensions (30% smaller than standard cylinders) with high lateral load capacity. Anti-rotation design ensures stable rod movement, while the hardened stainless steel guide bushing extends service life. Compatible with ISO 6432 mounting accessories.
- PCB handling robots in electronics assembly
- Dosing valve actuation in medical devices
- Label applicators in packaging lines
- Precision clamping in micro-machining
- Automated test equipment positioning
Installation note:
For optimal performance, adjust cushion screws gradually (max 1/4 turn increments) after installation.
Lubricate with ISO VG32 hydraulic oil if operating below 0℃. Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MFJ20X125-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
