Airtac MI25~40 Stainless Steel Mini Cylinder MI25X120SCA
$37.44
Regular price
$44.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MI25X120SCA
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 6432 standards (MI25~40 series, bore sizes 8~25mm);
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
Installation guidelines:
Use 2x M5 mounting screws (not included) with 0.6-0.8 N·m torque.
Lubricate with ISO VG32 turbine oil if operating below -10℃.
Maintain ≥2mm clearance around cylinder body for heat dissipation.
2. Integrated shock-absorbing pads on front/rear covers mitigate impact during direction changes;
3. Multiple rear cover configurations enhance installation flexibility;
4. Crimped and rolled structure ensures robust connection between stainless steel cylinder barrel and end covers;
5. Stainless steel piston rods and cylinders provide corrosion resistance for harsh operating environments;
6. Comprehensive range of specifications and mounting accessories available for customized solutions.
Category: Stainless Steel Mini Cylinders | Brand: AIRTAC | Series: MI25~40
AirTAC MI25X120SCA Stainless Steel Mini Cylinder Specifications
- Model: MI25X120SCA
- Series: MI25~40 stainless steel compact series
- Bore size: 25 mm
- Stroke: 120 mm (±1.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 150℃
- Port size: M5x0.8 (PT1/8 optional)
- Cushion type: Adjustable rubber buffer
- Mounting style: Front flange (MF1) with through holes
- Material: Stainless steel (SUS304 barrel, SUS303 rod)
- Seal material: Heat-resistant NBR (FKM available on request)
- Repeat positioning accuracy: ≤±0.5mm
- Max piston speed: 500 mm/s
- Weight: 0.82 kg (bare cylinder), 0.95 kg (with accessories
- Dimensions: 160mm(L) × 25mm(Bore Ø) × 42mm(Mounting height)
- Rod end thread: M6x1 internal thread (standard)
- ISO certification: 6431, VDMA 24562
Corrosion-resistant mini cylinder with reduced installation footprint (30% smaller than standard ISO cylinders). Features double-acting operation with magnetic piston for position sensing compatibility. Anti-rotation design maintains orientation stability in high-cycle applications.
Typical Applications:
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (washdown environments)
- Pharmaceutical tablet press ejection systems
- High-temperature furnace door actuators
- Precision optical lens positioning stages
Installation guidelines:
Use 2x M5 mounting screws (not included) with 0.6-0.8 N·m torque.
Lubricate with ISO VG32 turbine oil if operating below -10℃.
Maintain ≥2mm clearance around cylinder body for heat dissipation.
| Property | Property Value |
|---|---|
| sku | MI25X120SCA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 120mm |
