Airtac P-SDAD Repair Kit P-SDAD100-R1
AirTAC P-SDAD100-R1 Repair Kit Technical Details
- Model Compatibility: Designed for SDAD series cylinders (SDAD50~SDAD200)
- Kit Contents: 30 components including piston seals, rod seals, wipers, O-rings, and backup rings
- Seal Material: Polyurethane (PU) and Nitrile Rubber (NBR) combination
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Pressure Rating: Compatible with 0.05~1.0 MPa systems
- Chemical Resistance: Resists hydraulic oils (HL, HM), water glycol, and mild acids
- Weight: 350g ±5% (including packaging)
- Dimensions: 150mm(L) × 100mm(W) × 50mm(H)
- Shelf Life: 5 years in original packaging (store at 15-25℃, 40-60% RH)
- Certification: Complies with ISO 9001 and ISO/TS 16949 standards
Comprehensive maintenance solution for SDAD series compact cylinders, featuring wear-resistant sealing components with multi-lip design for enhanced dust exclusion. Includes anti-extrusion rings to prevent seal deformation under high pulsation pressures. Kit components are pre-lubricated with PFPE-based grease for immediate installation.
- Preventive maintenance in automated assembly lines
- Overhaul of pick-and-place pneumatic actuators
- Reconditioning food processing equipment cylinders
- Repairing packaging machinery with frequent stroke cycles
- Restoring medical device actuators requiring FDA-compliant materials
Maintenance protocol:
Replace entire seal set every 500,000 cycles or 2 years (whichever comes first).
Use alcohol-based cleaners only - petroleum solvents may degrade PU components.
Torque end caps to 12-15N·m during reassembly.
