Airtac P-SDAD Repair Kit P-SDAD16-R2
AirTAC P-SDAD16-R2 Repair Kit Technical Details
- Model: P-SDAD16-R2
- Compatible with: SDAD16 series cylinders
- Components: 42 precision parts (includes seals, O-rings, wear bands)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Temperature resistance: -30℃ to 120℃
- Pressure rating: 0.05-1.2 MPa
- Weight: 218g ±5g
- Dimensions: 120mm(L) × 85mm(W) × 35mm(H)
- Storage humidity: ≤75% RH (non-condensing)
- Shelf life: 5 years in original packaging
- Compliance: RoHS 2011/65/EU
Complete overhaul kit for SDAD16 pneumatic cylinders, containing all critical wear components. Features oil-resistant seals with extended cycle life (tested for 5,000km stroke endurance). Includes specialized installation tools: seal insertion pins and alignment jigs. Pre-lubricated with Kluber Staburags NBU 12/300 grease.
- Cylinder rebuilds after 1 million cycles
- Fluid contamination incidents (hydraulic oil mixing)
- Preventive maintenance in high-humidity environments
- Restoration of cylinders with ≥0.5mm rod scoring
Service protocol:
Always perform bore polishing (Ra ≤0.2μm) before installation.
Use torque-controlled assembly (3.5N·m max) for end caps.
Pressure test at 1.5×operating pressure for 30min post-repair.
