Airtac P-SDAD Repair Kit P-SDAD32-R1
AirTAC P-SDAD32-R1 Repair Kit Technical Details
- Model: P-SDAD32-R1
- Compatible Series: SDAD32 pneumatic actuators
- Material Composition:
- Seals: Hydrogenated Nitrile (HNBR)
- Springs: SUS304 stainless steel
- Guide Rings: Glass fiber reinforced POM
- Backup Rings: PTFE-coated polyurethane
- Temperature Range: -30℃ to 120℃
- Pressure Rating: 0.05–1.0 MPa
- Component Count: 18-piece set
- Weight: 285g ±5g (including packaging)
- Dimensions: 150mm(L) × 85mm(W) × 25mm(H)
- Storage Humidity: ≤70% RH (non-condensing)
- Shelf Life: 5 years in original sealed packaging
Complete overhaul kit for SDAD32 series compact cylinders, containing wear-resistant replacement components engineered for 500,000+ cycle durability. Features ozone-resistant seals and anti-corrosion treated metal parts, optimized for harsh industrial environments. Includes specialized installation tools: alignment pin and lip seal insertion guide.
- Preventive maintenance in automotive welding robots
- Field repair of packaging line gripper mechanisms
- Rebuilding contaminated actuators in food processing equipment
- Restoring precision motion in semiconductor handling systems
Maintenance protocol:
Replace all seals simultaneously using included directional markers.
Apply MIL-G-81322 grease to rod seals before installation.
Torque end caps to 3.2N·m ±10% using crisscross pattern.
| Property | Property Value |
|---|---|
| sku | P-SDAD32-R1 |
