Airtac P-SDAD Repair Kit P-SDAD40-R2
AirTAC P-SDAD40-R2 Cylinder Repair Kit Specifications
- Model: P-SDAD40-R2
- Compatible Cylinder Series: SDAD40/SDA40/SDAU40
- Bore Size: 40mm
- Material Composition:
- Seals: Polyurethane (PU) & Nitrile Butadiene Rubber (NBR)
- Wear Rings: Glass fiber reinforced polyester
- O-rings: HNBR (High-temperature resistant variant)
- Temperature Range: -20℃ to 100℃ (continuous operation)
- Pressure Rating: 0.05-1.2 MPa
- Lubrication: Pre-lubricated with Molykote EM-30L grease
- Package Contents: 28 components including piston seals, rod seals, buffer seals, guide rings, and scraper rings
- Weight: 380g ±5% (entire kit)
- Dimensions: 220mm(L) × 150mm(W) × 35mm(H) (blister package size)
- Storage Conditions: 5-35℃ in dry environment (5-year shelf life unopened)
Comprehensive maintenance solution for 40mm bore SDAD series cylinders, containing wear-resistant components engineered for high-cycle applications. Features anti-extrusion design for pressure spikes and PTFE-blended seals for reduced breakaway friction. Kit supports full overhaul including cushioning mechanism parts.
- Preventive maintenance in automated assembly lines
- Overhaul of packaging machinery actuators
- Rehabilitation of contaminated cylinders in foundry environments
- Servicing high-speed pick-and-place units (≥2m/s)
Maintenance protocol:
Replace all seals simultaneously using cleanroom-grade tools.
Post-installation, perform 5-10 slow strokes without load to seat components.
Compatible with ISO VG32 hydraulic oil lubrication.
Critical notice:
Do NOT mix old/new seal sets.
Buffer ring orientation must match original configuration -
consult cylinder's exploded diagram during reassembly.
