Airtac P-SDAD Repair Kit P-SDAD50-R1
$4.62
Regular price
$12.12
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
P-SDAD50-R1
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
Category: Cylinder Seal Kit
Brand: Airtac
Series: P-SDAD
Professional Description:
This Airtac P-SDAD Cylinder Seal Repair Kit is engineered for precision maintenance of pneumatic cylinders in industrial automation systems. The kit contains critical sealing components including O-rings, piston seals, rod seals, and wear bands specifically designed for P-SDAD series cylinders. Manufactured with HNBR/NBR materials for enhanced chemical resistance and durability, these seals ensure optimal cylinder performance under operating pressures up to 1.0 MPa and temperature ranges of -20°C to +80°C. Compliant with ISO 6431/15552 standards, this repair kit restores factory-grade sealing integrity while minimizing downtime in pneumatic actuator maintenance procedures.
Critical note:
Always replace entire seal set during maintenance - partial replacement
may cause uneven wear. Store unused components in original moisture-proof
packaging with desiccant.
AirTAC P-SDAD50-R1 Cylinder Repair Kit Technical Details
- Model compatibility: Designed for P-SDAD50 series cylinders
- Seal materials: NBR (standard) / PU (optional for chemical resistance)
- Component count: 23 precision parts including:
- 4x O-rings (φ42×2.4, φ32×2.4, φ20×2.4, φ12×1.8)
- 2x Wear-resistant piston rings
- 1x Rod seal (double-lip design)
- 3x Cushion seals
- 4x End cap gaskets
- 9x Specialty clips and retainers
- Temperature range: -30℃ to 100℃ (NBR) / -10℃ to 80℃ (PU)
- Pressure rating: 0.05-1.2 MPa
- Lubricant compatibility: ISO VG32 hydraulic oil or equivalent grease
- Package material: Anti-static PE bags with desiccant
- Weight: 185g ±5g
- Dimensions: 120mm(L) × 85mm(W) × 25mm(H)
- Certification: RoHS compliant
- Shelf life: 5 years in original packaging
Professional maintenance kit containing all wear-prone components for P-SDAD50 pneumatic cylinders. Features laser-etched part numbers for easy identification and anti-corrosion treated metal components. Includes both dynamic and static seals optimized for high-cycle applications.
Primary Applications:
- Preventive maintenance in high-duty-cycle automation lines
- Overhaul of contaminated cylinders in food processing equipment
- Restoration of pneumatic actuators in semiconductor manufacturing tools
- Field service repairs for logistics sorting systems
Replacement Protocol:
- Disassemble cylinder in ISO Class 7 equivalent clean environment
- Clean all metal components with non-residue solvent (IPA recommended)
- Lubricate seals with specified grease before installation
- Use torque wrench for end cap screws (12-15 N·m)
- Perform 50-cycle bench test before redeployment
Critical note:
Always replace entire seal set during maintenance - partial replacement
may cause uneven wear. Store unused components in original moisture-proof
packaging with desiccant.
| Property | Property Value |
|---|---|
| sku | P-SDAD50-R1 |
