Airtac QCKR Rotary Clamping Cylinder QCKR16X20SFB
$57.45
Regular price
$64.95
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
QCKR16X20SFB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Designed for welding environments, the piston rod undergoes QPQ treatment, providing enhanced resistance to weld spatter compared to hard chrome-plated surfaces;
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
Installation note:
Ensure mounting surface flatness ≤0.1mm. Apply thread lock (Loctite 243 recommended)
to M5x0.8 mounting screws. Perform 10-15 dry cycles before load operation.
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X20SFB Specifications
- Model: QCKR16X20SFB
- Type: Rotary clamping cylinder with auto-return mechanism
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa
- Rotation angle: 90° ±5°
- Port size: M5x0.8 (dual ports)
- Material: Aluminum alloy body, CRMo steel rotating shaft
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 70℃
- Clamping force: 28N at 0.5MPa
- Repeat accuracy: ±0.5mm
- Protection rating: IP40
- Weight: 380g ±5%
- Dimensions: 160mm(L) × 62mm(W) × 62mm(H)
Compact rotary clamp cylinder featuring dual-action rotary arm with precision ball bearing guides. Integrated shock absorption and anti-rotation pin ensure stable positioning. Requires 5μm filtered air and ISO VG32/46 hydraulic oil lubrication (optional).
Typical Applications:
- Fixture positioning in CNC machining centers
- Workpiece clamping in robotic welding stations
- PCB board retention in SMT assembly lines
- Modular tooling systems for automotive jigs
- Precision alignment in optical device manufacturing
Installation note:
Ensure mounting surface flatness ≤0.1mm. Apply thread lock (Loctite 243 recommended)
to M5x0.8 mounting screws. Perform 10-15 dry cycles before load operation.
| Property | Property Value |
|---|---|
| sku | QCKR16X20SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
