Airtac QCKR Rotary Clamping Cylinder QCKR16X20SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X20SMFB Technical Details
- Model: QCKR16X20SMFB
- Series: QCKR Compact Rotary Clamp
- Bore size: 16mm
- Stroke: 20mm
- Mounting type: Side flange (MFB designation)
- Operating pressure: 0.1–0.7 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard pneumatic interface)
- Rotation angle: 90° ±5° (automatic positioning)
- Repeat accuracy: ±0.5°
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (nitrile rubber)
- Weight: 0.65kg (without accessories)
- Dimensions: 140mm(L) × 60mm(W) × 60mm(H)
- Rod thread: M6x1.0 (clamp screw interface)
- Max lateral load: 5N·m
- Response time: ≤0.3s @ 0.5MPa
Compact rotary clamping cylinder combining linear thrust with 90° rotational motion for precision workpiece fixation. Features hardened guide rails for wear resistance and integrated T-slot for tooling plate compatibility. Requires 5μm filtered air and ISO VG32 lubricant for optimal performance.
- CNC machine tool fixture systems
- Automotive part clamping in robotic welding
- PCB board positioning in SMT assembly
- Modular jig systems for metrology equipment
- Pallet locking in automated production lines
Installation tip:
Align clamp axis within 0.2mm perpendicular tolerance during mounting.
Use thread locker on M6 clamp screw and cycle 5x without load before production use.
| Property | Property Value |
|---|---|
| sku | QCKR16X20SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
