Airtac QCKR Rotary Clamping Cylinder QCKR16X30SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X30SM Technical Details
- Model: QCKR16X30SM
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 30mm
- Operating pressure: 0.1-0.7 MPa
- Rotation angle: 90°±5°
- Mounting styles: Side-mount (standard), flange mount (optional)
- Cushioning: Adjustable rubber buffer
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Port size: M5x0.8 (1/8" NPT optional)
- Ambient temperature: -20℃ to +80℃
- Weight: 0.62kg ±2%
- Dimensions: 72mm(L) × 40mm(W) × 50mm(H) (excluding accessories)
- Protection class: IP40
- Lubrication: Pre-lubricated (recommended oil mist lubrication)
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring integrated T-slot for tooling plate attachment. The precision-ground guide rail ensures smooth rotation accuracy (±0.5° repeatability). Anti-rotation design prevents unintended pivoting during operation. Requires filtered air (5-50μm) with ISO VG32 hydraulic oil mist lubrication for optimal performance.
- CNC machine tool workpiece positioning
- Automated fixture systems for part flipping
- PCB handling robots with orientation adjustment
- Packaging line product rotation stations
- Automotive assembly jig clamping
Operation guidance:
Always engage manual override button during initial setup alignment.
Maintain 0.3-0.5 MPa air pressure during rotation phase for smooth motion.
Apply Loctite 243 to mounting screws (2.5Nm max torque).
| Property | Property Value |
|---|---|
| sku | QCKR16X30SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
