Airtac SAIJ160 Adjustable Cylinder SAIJ160AX165-75S
1. Compliant with ISO15552 standard (formerly ISO6431)
2. Features specially designed bidirectional piston sealing structure with compact dimensions and integrated oil reservoir functionality
3. Octagonal aluminum alloy tube construction without tie rods for enhanced corrosion resistance, equipped with sensor mounting slots for quick installation
4. Precision-engineered adjustable cushioning mechanism ensures smooth operation
5. Available with multiple cylinder specifications and comprehensive mounting accessory options
6. Utilizes high-temperature resistant sealing materials for operating temperature range of 0℃~150℃
Category: Standard Cylinders , Brand: AIRTAC , Series: SAIJ160
AirTAC SAIJ160AX165-75S Adjustable Cylinder Specifications
- Model: SAIJ160AX165-75S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø16mm
- Stroke: 165mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Port size: M5×0.8 (1/8")
- Cushioning: Adjustable rubber cushion (both ends)
- Operating temperature: -20℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR rubber seals
- Mounting style: Foot-mounted (Standard ISO 15552)
- Weight: 1.52kg ±2%
- Dimensions (L×W×H): 328mm × 60mm × 60mm (extended length)
- Repeat positioning accuracy: ±0.5mm
- Max theoretical thrust: 126N @0.6MPa
- Protection rating: IP40 (dust protected)
Precision-adjustable pneumatic cylinder featuring micro-stroke tuning via 360° rotatable stroke adjusters. The dual-channel design minimizes lateral load stress, while the chrome-plated piston rod resists corrosion in humid environments. Includes magnetic piston for sensor compatibility and auto-locking adjustment mechanism to prevent accidental position shifts.
- Precision workpiece positioning in CNC machine tools
- Variable height adjustment in packaging conveyors
- Clamping force control in fixture systems
- Material feeding mechanisms with position feedback
- Automated door stroke limitation in cleanrooms
Installation note:
For optimal performance, maintain 0.5-1mm clearance between stroke adjusters and mechanical stops.
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side-load exceeding 15N during alignment.
| Property | Property Value |
|---|---|
| sku | SAIJ160AX165-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | 160mm |
| Stroke | 165 mm |
