Airtac SE80 Standard Cylinder SE80AX10
The AirTAC Airtac SE80 Standard Cylinder SE80AX10 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 10mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke10 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX10
The AirTAC SE80AX10 is a double-acting single-rod ISO 15552 profile cylinder engineered for short-stroke heavy pushing, delivering 2513 N of thrust at 0.5 MPa. Its extruded aluminum square barrel omits external tie rods entirely, yielding a flush exterior that resists corrosion and simplifies bracket mounting in tight machinery cells.
This specific SKU utilizes a SUS420J2 stainless steel piston rod (code A) to withstand corrosive environments and washdown cycles. It operates without a position-sensing magnet, relying instead on its field-adjustable pneumatic cushioning at both ends to decelerate the 25mm rod smoothly near the 10mm stroke endpoints.
Airtac SE80 Standard Cylinder SE80AX10 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX10 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX10
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX10 Is Used
Stamping Press Ejection
Uses the 2513 N push force at 0.5 MPa to knock stamped metal parts out of a die, leveraging the SUS420J2 rod to resist cutting fluid splash.
Carton Flap Folding
Employs the short 10mm stroke to rapidly tuck inner flaps on high-speed packaging lines, where the flush extruded barrel prevents snagging on passing cardboard.
Lab Dispenser Clamping
Secures chemical dispenser nozzles in a washdown environment, relying on the stainless steel rod material to prevent corrosion during daily sanitation cycles.
Is the Airtac SE80 Standard Cylinder SE80AX10 the Right Cylinder?
When sizing this 80mm bore actuator, evaluate your thrust requirements carefully: stepping down to a 63mm bore reduces the 0.5 MPa push to 1559 N, while stepping up to a 100mm bore increases it to 3927 N. Because this plain SE variant lacks a rod lock, it cannot hold a load mechanically if air pressure drops or the valve centers—the piston will drift, requiring an external pilot-operated check valve for position holding.
As a true ISO 15552 profile cylinder, it serves as a drop-in dimensional replacement for competing standard cylinders, matching the 80mm PT3/8 port and standardized mounting interface. For short 10mm movements, the robust 25mm rod thread handles high side loads without deflection, though an external guide is always recommended for absorbing true lateral forces.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX10 FAQ
The 80mm bore generates a push force of 2513 N and a pull force of 2268 N at 0.5 MPa. At 0.7 MPa, the push force is 3518 N, with a maximum push capacity of 513 kgf at 1.0 MPa. It features a 25mm SUS420J2 stainless steel rod with an M20x1.5 thread.
Yes, the SE80AX10 is dimensionally interchangeable with any standard ISO 15552 profile cylinder, sharing the same mounting footprint and PT3/8 port size. Note that this specific SKU lacks a sensor magnet, so it cannot host CMSE or DMSE electronic switches without modifying the piston assembly.
