Airtac SE80 Standard Cylinder SE80X200
The AirTAC Airtac SE80 Standard Cylinder SE80X200 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 200mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke200 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80X200
The AirTAC SE80X200 is a double-acting, single-rod ISO 15552 profile cylinder engineered for demanding pneumatic tasks. It provides a robust 2513 N push force at 0.5 MPa and utilizes a PT3/8 port paired with a 25 mm hard-chrome plated rod. Designed with a square extruded aluminum barrel, it eliminates external tie rods entirely, yielding a compact, corrosion-resistant body that mounts flush against machine frames.
This 80 mm bore unit features field-adjustable air cushioning at both stroke ends, allowing technicians to dial in end-of-stroke deceleration and eliminate hard metal impacts during high-speed operations. Because this specific SKU lacks the -S magnet code, it does not support CMSE or DMSE electronic position sensing out of the box. If your workflow requires intermediate stopping or load holding without constant air pressure, consider pairing an external guide with the BSE rod-lock variant.
Airtac SE80 Standard Cylinder SE80X200 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80X200 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80X200
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80X200 Is Used
CNC Lathe Bar Feeder
Pushes raw steel bar stock through the lathe spindle with 2513 N of thrust at 0.5 MPa, utilizing the 200 mm stroke to index material precisely without external tie-rod obstructions blocking the feeder carriage.
Pallet Diverting Gate
Actuates a heavy-duty routing gate on a 50 kg pallet conveyor line, relying on the field-adjustable pneumatic cushions to soften the 200 mm stroke impact during high-speed 30-800 mm/s routing cycles.
Corrugated Box Flap Folder
Drives the side folding mechanism on an automated carton erector, where the 80 mm bore's 513 kgf maximum output ensures crisp, square folds on heavy double-walled corrugated cardboard materials.
Is the Airtac SE80 Standard Cylinder SE80X200 the Right Cylinder?
When sizing this 80 mm bore actuator, evaluate your exact thrust margins: the SE80X200 generates 2513 N of push force at 0.5 MPa. If your application demands less force and a smaller footprint, step down to the 63 mm bore, which yields 1559 N of push at 0.5 MPa. Conversely, if you need substantially higher thrust, stepping up to the 100 mm bore provides 3927 N of push at 0.5 MPa. As a true ISO 15552 cylinder, it serves as a dimensionally interchangeable drop-in replacement for other ISO 15552 profile cylinders, matching standard mounting hardware and footprint dimensions exactly.
With its 200 mm stroke, the 25 mm rod and internal bearing see moderate extension, but for any stroke length of 300 mm or more, you must account for side-load bending and utilize an external guide to prevent premature rod-bearing wear. Remember that the standard double-acting SE design relies on live air pressure to maintain position; the adjustable cushion only decelerates the piston near stroke end and will not hold a load if air is exhausted.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80X200 FAQ
The SE80X80 generates 2513 N of push force and 2268 N of pull force at 0.5 MPa. At 0.7 MPa, the push force is 3518 N, with an absolute maximum push of 513 kgf at 1.0 MPa. It operates at speeds between 30-800 mm/s, uses a PT3/8 port, and features a 25 mm rod with an M20x1.5 thread.
No, the standard SE80X200 is a double-acting cylinder and will drift if air is lost or the valve is centered. The adjustable air cushions at both ends only decelerate the piston near the stroke limits; they are not locking mechanisms. For positive load holding, you need the BSE variant with a rod lock or an external pilot-operated check valve.
