Airtac SE80 Standard Cylinder SE80AX1000
The AirTAC Airtac SE80 Standard Cylinder SE80AX1000 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX1000
The AirTAC SE80AX1000 is a double-acting ISO 15552 profile cylinder engineered for a 1000 mm stroke, delivering 2513 N of push force at 0.5 MPa. Its extruded aluminum barrel omits external tie rods, yielding a compact, flush-mounting body that naturally resists corrosion and physical snagging in tight machine cells. The SUS420J2 stainless steel rod (material code A) specifically targets washdown and mildly corrosive environments where standard carbon steel rods would pit or degrade.
Because this 1000 mm stroke pushes the limits of the bore 80 platform, the field-adjustable air cushioning at both ends becomes critical—it uses a needle screw to tune end-of-stroke deceleration rather than relying on a fixed rubber bumper. Note that this SKU lacks a built-in magnet, so it cannot directly host CMSE or DMSE position sensors without modification. The piston operates at 30-800 mm/s via PT3/8 ports, but remember the cushion only softens impact; it provides no holding force if air pressure drops.
Airtac SE80 Standard Cylinder SE80AX1000 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX1000 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX1000
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX1000 Is Used
Pallet Strapping Press
Applies 2513 N of clamping force at 0.5 MPa to tension and seal heavy-duty polyester strapping around outbound shipping pallets without manual leverage.
Washdown Fluid Diverter
Leverages the SUS420J2 stainless rod to reliably actuate a 1000 mm stroke diverting blade in a food-grade washdown environment, routing product between processing lines.
Multi-Tier Elevator Pusher
Uses the full 1-meter extension to transfer heavy totes between automated storage retrieval system (ASRS) tiers, relying on adjustable cushions to stop the massive payload smoothly.
Is the Airtac SE80 Standard Cylinder SE80AX1000 the Right Cylinder?
At 0.5 MPa, this 80 mm bore generates 2513 N of push force. If your payload is lighter, stepping down to the 63 mm bore yields 1559 N of push, whereas upgrading to the 100 mm bore provides 3927 N for heavier loads. For a 1000 mm stroke, the Ø25 mm rod and M20x1.5 thread carry substantial side-load capacity, but an unsupported piston of this length is highly prone to rod-bearing bending; you must use an external linear guide to prevent catastrophic seal failure and stick-slip friction. As a true ISO 15552 profile cylinder, it offers drop-in dimensional interchangeability with other standard ISO 15552 mounting hardware for direct retrofits. Since this unit has no -S magnet, position sensing requires external methods. Furthermore, if your process requires the load to stay fixed during an air-loss event, the cushion cannot act as a brake—you must integrate a BSE rod lock or an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX1000 FAQ
At 0.5 MPa, this 80 mm bore cylinder provides 2513 N of push force and 2268 N of pull force. At 0.7 MPa, the push force increases to 3518 N. The absolute maximum push capacity is 513 kgf when operating at the 1.0 MPa pressure limit.
No. The field-adjustable air cushion at both ends only decelerates the piston near the stroke end; it is not a locking mechanism. If the air supply is lost or the valve is centered, the piston will drift. To hold a vertical load safely, you must add an external rod lock or use a BSE variant.
