Airtac SE80 Standard Cylinder SE80AX100S
The AirTAC Airtac SE80 Standard Cylinder SE80AX100S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 100mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke100 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX100S
The AirTAC SE80AX100S is a double-acting single-rod profile cylinder built to ISO 15552 standards, delivering a robust 2513 N push force at 0.5 MPa. It features an 80 mm bore, a 100 mm stroke, and a PT3/8 port. The square extruded aluminum barrel lacks external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while leaving the integrated sensor grooves fully accessible.
This specific configuration includes a SUS420J2 stainless steel rod (option A) for enhanced resistance in corrosive or washdown environments, and a built-in magnet (option S) for position detection. Field-adjustable pneumatic cushioning at both ends allows you to tune end-of-stroke deceleration via a set screw, softening hard impacts when cycling heavy loads at speed.
Airtac SE80 Standard Cylinder SE80AX100S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX100S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX100S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX100S Is Used
Palletizer Strapping
Drives the strapping head on an automated palletizer, using the 2513 N push force to tension and seal steel bands around heavy loads.
Press Brake Backgauge
Positions the backgauge finger on a CNC press brake, relying on the 100 mm stroke and SUS420J2 rod to withstand coolant splash and shop debris.
Washdown Conveyor Diverter
Actuates a diverting gate on a food-grade conveyor line, where the stainless steel rod and tie-rod-free extruded barrel resist high-pressure washdowns.
Is the Airtac SE80 Standard Cylinder SE80AX100S the Right Cylinder?
Stepping down to the 63 mm bore reduces the 0.5 MPa push to 1559 N, whereas moving up to the 100 mm bore increases it to 3927 N, letting you scale thrust precisely for your application. Because this is a double-acting cylinder, it cannot hold a load if air pressure is lost or the valve centers; the piston will drift. For position-holding safety, consider the BSE rod-lock variant or an external pilot-operated check valve. To match this unit for an ISO 15552 retrofit, specify the 80 mm bore, 100 mm stroke, PT3/8 port, desired mounting accessory, and the -S magnet requirement.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX100S FAQ
At 0.5 MPa, this 80 mm bore cylinder provides 2513 N of push force and 2268 N of pull force. At 0.7 MPa, the push force is 3518 N. The maximum push force is 513 kgf at 1.0 MPa operating pressure.
Yes. The SE80AX100S is dimensionally interchangeable per ISO 15552, serving as a drop-in replacement for other standard profile cylinders. It uses a PT3/8 port and includes a built-in magnet compatible with AirTAC CMSE reed and DMSE electronic sensors.
