AirTAC SE Series · ISO 15552 Cylinder

Airtac SE80 Standard Cylinder SE80AX105

The AirTAC SE80 Standard Cylinder SE80AX105 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 105mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ80 mm
  • Stroke105 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM20×1.5
  • CushionAdjustable, 36 mm
$160.02 $167.52Save 4% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE80 stroke, mounting and version on one page All SE80 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE80 Standard Cylinder SE80AX105

The AirTAC SE80AX105 is a double-acting, single-rod ISO 15552 profile cylinder engineered for heavy-duty pneumatics. It delivers a robust 2513 N push force at 0.5 MPa and utilizes a 105 mm stroke. Built with a SUS420J2 stainless steel piston rod, this variant is specifically designed to resist corrosion in washdown or chemically harsh environments.

Unlike traditional tie-rod units, its extruded aluminum barrel features a clean, flush profile that prevents debris accumulation and simplifies mounting. The cylinder incorporates field-adjustable air cushioning at both ends, allowing technicians to precisely tune end-of-stroke deceleration and eliminate hard impact damage, rather than relying on fixed rubber bumpers.

Airtac SE80 Standard Cylinder SE80AX105 Technical Specifications

ModelAirtac SE80 Standard Cylinder SE80AX105
SeriesSE ISO 15552 profile cylinder
Bore sizeØ80 mm
Stroke105 mm
Acting typeDouble acting
Port sizePT3/8
Rod threadM20×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø80mm)

PressurePush forcePull force
0.5 MPa2513 N2268 N
0.7 MPa3519 N—
Max (@1.0 MPa)513 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE80 Standard Cylinder SE80AX105

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
80Bore size in mm.
×105Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE80 Standard Cylinder SE80AX105 Is Used

package_2

Palletizer Pusher

Drives heavy corrugated cardboard cartons onto pallets using its 2513 N push force, while the SUS420J2 rod survives humid packaging plant washdowns.

science

Chemical Dip Ejection

Extracts treated parts from a plating bath, relying on the 105 mm stroke and stainless rod to withstand caustic vapor exposure.

precision_manufacturing

CNC Lathe Unloader

Ejects finished metal rings from the spindle, using the adjustable pneumatic cushion to protect the spindle bearings from end-stop shock.

Is the Airtac SE80 Standard Cylinder SE80AX105 the Right Cylinder?

Delivering 2513 N push at 0.5 MPa, this 80 mm bore cylinder sits perfectly between the 63 mm class (1559 N push) and the 100 mm class (3927 N push), allowing you to scale up or down depending on your exact payload. To match existing infrastructure, it uses a PT3/8 port, an M20x1.5 rod-end thread, and standard ISO 15552 mounting accessories. Note that this SKU lacks a built-in magnet, so it cannot support CMSE or DMSE position sensors without a model change. Furthermore, a standard SE cylinder will drift if air pressure is lost; if your application requires static load holding during power failure, you must integrate an external BSE rod lock or pilot-operated check valve.

AirtacDistr lists every SE80 order code with its price on one page at https://airtacdistr.com/products/airtac-se80-iso-air-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE80 Standard Cylinder SE80AX105 FAQ

At 0.5 MPa, it provides 2513 N of push force and 2268 N of pull force. At 0.7 MPa, the push force reaches 3518 N, with a maximum push capacity of 513 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.

Yes. The SE80AX105 is dimensionally interchangeable per ISO 15552 standards, meaning it serves as a direct replacement for other ISO 15552 profile cylinders using the same mounting interface and PT3/8 port size.
