Airtac SE80 Standard Cylinder SE80AX110
The AirTAC Airtac SE80 Standard Cylinder SE80AX110 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 110mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke110 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX110
The AirTAC SE80AX110 is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering a robust 2513 N push force at 0.5 MPa. It features a hard-chrome SUS420J2 stainless steel rod (material code A) engineered specifically for corrosive environments and washdown duty. The square extruded aluminum barrel omits external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting contamination buildup.
This 80 mm bore unit operates at speeds from 30-800 mm/s and relies on field-adjustable air cushioning at both ends to decelerate the piston near stroke end. Because this SKU lacks the -S magnet code, it is not equipped for direct CMSE or DMSE position sensing without modification. The cushioning is a true adjustable screw mechanism, not a fixed rubber bumper, allowing you to tune end-stop softness based on the moving load.
Airtac SE80 Standard Cylinder SE80AX110 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX110 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX110
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX110 Is Used
Food Processing Diverter
Uses the SUS420J2 stainless rod to withstand daily washdown chemicals while routing heavy product flow with 2513 N of push force.
Pallet Case Erector
Employs the 110 mm stroke and adjustable end cushions to smoothly fold corrugated cardboard blanks without crushing the material.
CNC Fixture Clamping
Leverages the 0.15-1.0 MPa operating range and 513 kgf max hold to secure heavy cast iron engine blocks during high-speed machining.
Is the Airtac SE80 Standard Cylinder SE80AX110 the Right Cylinder?
Selecting this 80 mm bore makes sense when your application requires substantial thrust. If you need to step down, the 63 mm bore offers 1559 N push at 0.5 MPa; if you need to step up, the 100 mm bore provides 3927 N push at 0.5 MPa. As a true ISO 15552 profile cylinder, the SE80AX110 is dimensionally interchangeable with other ISO 15552 cylinders, allowing a drop-in replacement using existing mounting hardware like FA front flanges or LB foot brackets without machining new plates.
Note that a plain double-acting cylinder does not hold its position or load when air is lost or the valve is centred, as the piston will drift. If your setup must hold a vertical load without live pressure, consider the BSE rod lock variant. Furthermore, while the 25 mm rod and M20x1.5 thread handle high side loads, any stroke of 300 mm or more requires an external guide to prevent rod-bearing bending.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX110 FAQ
At 0.5 MPa, this 80 mm bore cylinder provides 2513 N push and 2268 N pull. At 0.7 MPa, the push increases to 3518 N. The maximum push is 513 kgf at 1.0 MPa. It operates at a speed range of 30-800 mm/s.
Yes, the SE80AX110 is dimensionally interchangeable per ISO 15552 standards. You can use it as a drop-in replacement for other ISO 15552 profile cylinders, matching the 80 mm bore, 110 mm stroke, PT3/8 port, and standard mounting dimensions without altering your machine plate.
