Airtac SE80 Standard Cylinder SE80AX110S
The AirTAC Airtac SE80 Standard Cylinder SE80AX110S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 110mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke110 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX110S
The AirTAC SE80AX110S is a double-acting, single-rod ISO 15552 profile cylinder engineered for heavy-duty linear motion. It delivers a robust 2513 N push force at 0.5 MPa, utilizing an 80 mm bore and a 110 mm stroke. The square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while freeing up the outer surface for direct sensor placement.
This specific configuration features a SUS420J2 stainless steel rod (code A) for superior resistance to corrosion and washdown chemicals. Equipped with a built-in magnet (code S), the cylinder is fully compatible with AirTAC CMSE reed and DMSE electronic sensors for precise end-position detection. The field-adjustable pneumatic cushioning at both ends allows technicians to tune the end-of-stroke deceleration, absorbing kinetic energy smoothly rather than relying on a fixed bumper.
Airtac SE80 Standard Cylinder SE80AX110S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX110S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX110S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX110S Is Used
CNC Fixture Clamping
Provides 2513 N of clamping thrust at 0.5 MPa to secure heavy cast iron engine blocks during high-speed CNC machining operations.
Pallet Dispenser Pusher
Utilizes the 110 mm stroke and SUS420J2 stainless rod to push and separate empty wooden pallets in humid washdown packaging environments.
Injection Mold Ejection
Delivers reliable ejection force for dense plastic automotive interior components, using DMSE electronic sensors to confirm mold clearance.
Is the Airtac SE80 Standard Cylinder SE80AX110S the Right Cylinder?
Selecting the SE80AX110S is optimal when an application requires substantial thrust between the 63 mm and 100 mm bore classes. Stepping down to a 63 mm bore reduces the 0.5 MPa push to 1559 N, while stepping up to a 100 mm bore increases it to 3927 N. This 80 mm model provides a balanced 2513 N push, paired with a PT3/8 port and a sturdy Ø25 mm rod to handle significant side loads. As a true ISO 15552 profile cylinder, it serves as a drop-in dimensional replacement for any standard 80 mm ISO 15552 cylinder, matching mounting footprint and accessory interfaces exactly. Note that the adjustable air cushion decelerates the piston near stroke end but does not lock or hold the load; if position holding is required without live air pressure, a BSE rod lock variant or external pilot check valve is necessary.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX110S FAQ
The SE80AX110S generates 2513 N of push force and 2268 N of pull force at 0.5 MPa. At 0.7 MPa, the push force increases to 3518 N. The maximum push force is 513 kgf at 1.0 MPa. It operates at a speed range of 30-800 mm/s.
Yes, the SE80AX110S is dimensionally interchangeable per ISO 15552 standards. You can use it as a drop-in replacement for other 80 mm ISO 15552 profile cylinders, matching the PT3/8 port, 110 mm stroke, and standard mounting dimensions without modifying the machine frame.
