Airtac SE80 Standard Cylinder SE80AX125S
The AirTAC Airtac SE80 Standard Cylinder SE80AX125S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 125mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke125 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX125S
The AirTAC SE80AX125S is a double-acting single-rod ISO 15552 profile cylinder engineered for heavy-duty pneumatics. It delivers a robust 2513 N push force at 0.5 MPa (3518 N at 0.7 MPa) across a 125 mm stroke. The extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against frames while resisting mechanical snagging.
This specific configuration features a SUS420J2 stainless steel rod (code A) for superior resistance to washdowns and corrosive environments. The built-in magnet (code S) directly supports AirTAC CMSE reed and DMSE electronic position sensing. Furthermore, the field-adjustable pneumatic cushioning at both ends allows technicians to dial in end-of-stroke deceleration via a set screw, softening hard impacts during high-speed 30-800 mm/s operations.
Airtac SE80 Standard Cylinder SE80AX125S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX125S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 125 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX125S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×125 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX125S Is Used
Corrugated Box Folding
Drives heavy folding mechanisms on corrugated packaging lines, utilizing the 2513 N push force and SUS420J2 stainless rod to withstand abrasive paper dust and frequent washdowns.
Bottling Line Diverter
Actuates heavy lane diverter gates on high-speed bottling conveyors, relying on the 125 mm stroke and DMSE electronic sensors for rapid, precise routing of glass containers.
Injection Mold Ejection
Provides secondary ejection force for injection molding machines, where the 3518 N thrust at 0.7 MPa safely separates dense plastic parts from stubborn mold cavities.
Is the Airtac SE80 Standard Cylinder SE80AX125S the Right Cylinder?
If 2513 N push at 0.5 MPa is excessive for your load, step down to the 63 mm bore, which yields 1559 N. If you need more thrust, the 100 mm bore provides 3927 N. Because this is a standard ISO 15552 profile cylinder, it serves as a drop-in dimensional replacement for other ISO 15552 cylinders, sharing standardized mounting hardware like FA front flanges or TC center trunnions.
The 125 mm stroke is well within standard limits, but note that the plain SE cylinder cannot hold a load or maintain its position if air pressure drops or the valve centers—the piston will drift. For critical load-holding safety, consider the BSE rod-lock variant. The adjustable air cushion only decelerates the piston near stroke end; it does not act as a brake.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX125S FAQ
The SE80AX125S (80 mm bore, 125 mm stroke) delivers 2513 N push and 2268 N pull at 0.5 MPa, 3518 N push at 0.7 MPa, and a maximum of 513 kgf at 1.0 MPa. It uses a PT3/8 port, a Ø25 mm rod, and an M20x1.5 rod-end thread.
Yes, the SE80AX125S is dimensionally interchangeable per ISO 15552 / VDMA 24562 standards. You can drop it in as a replacement for other ISO 15552 profile cylinders using existing mounting accessories, while the built-in magnet enables AirTAC CMSE and DMSE sensors for seamless automation integration.
