Airtac SE80 Standard Cylinder SE80AX130S
The AirTAC Airtac SE80 Standard Cylinder SE80AX130S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 130mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke130 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX130S
The AirTAC SE80AX130S is a double-acting, single-rod ISO 15552 profile cylinder engineered for rigorous motion control. It generates 2513 N of push force at 0.5 MPa and features a 130 mm stroke. The square extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while protecting internal mechanics from washdown environments.
Equipped with a SUS420J2 stainless steel rod (code A), this unit resists rust and chemical exposure in wet processing areas. The integrated magnet (-S) directly interfaces with AirTAC CMSE reed and DMSE electronic sensors for precise end-of-stroke detection. Furthermore, the field-adjustable air cushioning at both ends allows technicians to tune end-cap deceleration via a set screw, softening hard mechanical stops during high-speed 30-800 mm/s cycles.
Airtac SE80 Standard Cylinder SE80AX130S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX130S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX130S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX130S Is Used
Food Processing Diverters
Leverages the SUS420J2 stainless rod to withstand daily washdown chemistry while providing 2513 N push force to pivot heavy product routing gates on packaging lines.
CNC Fixture Clamping
Delivers reliable 2268 N retract force to secure heavy cast iron automotive housings, using the DMSE electronic sensor to confirm clamp engagement before machining starts.
Pallet Accumulation Stops
Absorbs repeated high-speed 30-800 mm/s impacts from pallets using field-adjustable end cushions, preventing premature wear on the 25 mm rod and M20x1.5 thread.
Is the Airtac SE80 Standard Cylinder SE80AX130S the Right Cylinder?
If 2513 N push at 0.5 MPa is too much force, stepping down to the 63 mm bore yields 1559 N. Conversely, scaling up to the 100 mm bore provides 3927 N for heavier payloads. Because the SE80AX130S uses a PT3/8 port and an M20x1.5 rod thread, it matches standard ISO 15552 mounting dimensions exactly, ensuring a drop-in retrofit for existing ISO cylinders without altering pin or bolt patterns. Remember that the adjustable air cushion only decelerates the piston near stroke end; it cannot hold a vertical load if air pressure drops. For position holding, use a BSE rod lock or external pilot-operated check valve. At 130 mm stroke, side-load stress on the rod bearing is minimal, but always verify guide alignment.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX130S FAQ
The SE80AX130S generates 2513 N push and 2268 N pull at 0.5 MPa, 3518 N push at 0.7 MPa, and a maximum of 513 kgf at 1.0 MPa. It uses a PT3/8 port and a 25 mm rod with an M20x1.5 thread.
Yes, the SE80AX130S is dimensionally interchangeable per ISO 15552 standards, meaning it shares identical mounting and pin dimensions. You can drop it into existing ISO 15552 hardware, provided the 130 mm stroke and PT3/8 port match your current setup.
