Airtac SE80 Standard Cylinder SE80AX135
The AirTAC Airtac SE80 Standard Cylinder SE80AX135 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 135mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke135 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX135
The AirTAC SE80AX135 is a double-acting, single-rod ISO 15552 profile cylinder engineered for an 80 mm bore and a 135 mm stroke. It delivers a robust 2513 N push force at 0.5 MPa, scaling to 3518 N at 0.7 MPa, making it well-suited for heavy-duty positioning and high-load actuation. The extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while preventing dirt accumulation along the cylinder length.
This specific SKU features a SUS420J2 stainless steel rod (material code A) designed to endure washdowns and mildly corrosive environments. Unlike fixed rubber bumpers, it integrates field-adjustable pneumatic cushioning at both ends, allowing technicians to tune end-of-stroke deceleration via a set screw to soften hard impacts at high cycling speeds. Note that this configuration lacks the -S magnet option, meaning it is not wired for AirTAC CMSE or DMSE position sensing out of the box.
Airtac SE80 Standard Cylinder SE80AX135 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX135 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 135 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX135
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×135 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX135 Is Used
Thermoformer Press
Drives the forming press in a food packaging line, utilizing the 2513 N push force to mold plastic trays while the SUS420J2 rod withstands routine washdowns.
Metal Stamping Ejector
Ejects stamped brackets from a hydraulic press, relying on the 135 mm stroke and adjustable end-cushions to absorb sudden kinetic energy at high speed.
Pulp & Paper Gating
Actuates a heavy diverter gate in a moist pulp processing facility, where the corrosion-resistant stainless rod and tie-rod-free extruded profile prevent fiber buildup.
Is the Airtac SE80 Standard Cylinder SE80AX135 the Right Cylinder?
When sizing this 80 mm bore actuator, consider stepping down to the 63 mm variant if your load requires only 1559 N of push force at 0.5 MPa, or stepping up to the 100 mm bore if you need a substantially higher 3927 N thrust. Because the 135 mm stroke is relatively short, the rigid Ø25 mm rod and M20x1.5 thread handle side loading well without an external guide. Remember that the adjustable air cushion only decelerates the piston near the stroke ends; it does not hold a load. If your application loses air pressure and must prevent drift, you must integrate a BSE rod lock or an external pilot-operated check valve. As a true ISO 15552 profile cylinder, it serves as a drop-in replacement for any standard ISO 15552 unit, utilizing the same PT3/8 port and standardized mounting accessories.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX135 FAQ
The SE80AX135 generates 2513 N of push force and 2268 N of pull force at 0.5 MPa. At 0.7 MPa, the push force is 3518 N, with a maximum push capacity of 513 kgf at 1.0 MPa. It features a PT3/8 port and a 36 mm cushion length.
No, the standard double-acting SE cylinder does not hold position unpowered. The field-adjustable air cushions only decelerate the piston near the stroke ends; they are not brakes. For fail-safe load holding, consider the AirTAC BSE series with an integrated rod lock.
