AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-100S

The AirTAC SEJ Adjustable Cylinder SEJ32X125-100S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 100mm window, so this Ø32mm unit covers an effective stroke of 25–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window100 mm
  • Effective stroke25–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-100S

The AirTAC SEJ32X125-100S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 100mm adjustable stroke window. You can dial the retract end from 25mm up to the 125mm nominal stroke, allowing precise end-position tuning without swapping hardware. A rod exits both ends, providing equal force and speed in both directions.

This 32mm bore generates 345 N each way at 0.5 MPa. The rear rod accommodates a cam or flag and includes an M10x1.25 thread. Equipped with a magnet, it supports CMSE reed and DMSE electronic sensors. Adjustable air cushions at both ends manage deceleration near stroke completion.

Airtac SEJ Adjustable Cylinder SEJ32X125-100S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-100S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window100 mm (25–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 100mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-100S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-100Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-100S Is Used

swap_horiz

Multi-Part Changeover

Rapidly adjusting the retract stop to accommodate different part heights on a packaging conveyor without replacing the entire cylinder assembly.

science

Prototype Positioning

Testing actuation distances on R&D lab equipment by sweeping the 100mm window to find the optimal mechanical end position before finalizing a design.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-100S the Right Cylinder?

This 100mm adjustment window is ideal for prototyping jigs where the exact extend stop is unknown. If you need less variability, the fixed-stroke SED is sufficient. For sizing, the next bore down does not exist in this series, but stepping up to a 40mm bore yields 528 N at 0.5 MPa. A plain SEJ does not hold position on air loss; use an external rod lock for fail-safe holding. As a dimensionally interchangeable ISO 15552 cylinder, it replaces any standard 32mm bore, 125mm stroke, PT1/8 port unit with a 100mm adjustment requirement.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (100mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 100mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-100S FAQ

A stop screw on the back rod mechanically shortens the retract stroke over a 100mm window. You can set the effective stroke anywhere from 25mm to 125mm, then lock it in place.

The double-rod design provides equal force both ways: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa. It operates between 0.15 and 1.0 MPa.
