AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-10S

The AirTAC SEJ Adjustable Cylinder SEJ32X125-10S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 10mm window, so this Ø32mm unit covers an effective stroke of 115–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window10 mm
  • Effective stroke115–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-10S

The AirTAC SEJ32X125-10S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 10mm adjustable stroke window. A rod exits both ends, yielding identical annulus areas so thrust is equal in both directions at 345 N each way at 0.5 MPa. You can dial the retract end from 115mm up to the 125mm nominal stroke via a back-rod stop screw.

This 32mm bore unit runs on PT1/8 ports with a 12mm rod and M10x1.25 thread. The extruded aluminum barrel carries no external tie rods, and adjustable air cushions at both ends decelerate the load near stroke end. The built-in magnet supports CMSE reed and DMSE electronic sensors for position confirmation.

Airtac SEJ Adjustable Cylinder SEJ32X125-10S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-10S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window10 mm (115–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 10mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-10S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-10Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-10S Is Used

precision_manufacturing

Pick-and-Place Height Tuning

Dial the 10mm retract window to hit exact product heights on a packaging line, using the equal 345 N both-way force to lift and lower without thrust imbalance.

straighten

Press Fit Commissioning

Fine-tune the end position during machine commissioning to set precise insertion depth, locking the back-rod stop screw once the 115-125mm range is verified.

swap_horiz

Changeover Stop Adjustment

Quickly adapt the retract stop for different part profiles on a conveyor transfer, shifting the effective stroke within the 10mm window without swapping hardware.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-10S the Right Cylinder?

Verify your end-position tolerance fits within the 10mm adjustment window before commissioning. If you need less force, the adjacent 32mm bore is the smallest available here; if you need more thrust, step up to the 50mm bore which delivers 825 N each way at 0.5 MPa. If your stroke never changes after setup, a fixed-stroke SED avoids the extra length. Remember that the stop screw and air cushions only set the mechanical end and decelerate motion; they do not hold position on air loss, so specify an external rod lock for fail-safe holding.

For an ISO 15552 replacement match, confirm the 125mm nominal stroke, 10mm window, PT1/8 port, and your required mounting from the SEJ set (Basic, FA, LB, TC, FTC, TCM1, TCM2). At 125mm stroke, external guides are recommended to prevent side-load damage to the 12mm rod.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (10mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 10mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-10S FAQ

A stop screw on the back rod lets you mechanically shorten the retract stroke within a 10mm window. The effective stroke range is 115mm to 125mm. You dial it in during setup and lock the screw to hold that exact end position.

Because it is a double-rod cylinder, the force is identical in both directions. It delivers 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
