AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-10SN

The AirTAC SEJ Adjustable Cylinder SEJ32X125-10SN is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 10mm window, so this Ø32mm unit covers an effective stroke of 115–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window10 mm
  • Effective stroke115–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-10SN

The AirTAC SEJ32X125-10SN is a double-acting, double-rod ISO 15552 profile cylinder featuring a 10 mm adjustable stroke window. A rod exits both ends, yielding identical annulus areas so output force is equal in both directions at 345 N each way at 0.5 MPa. You can dial the retract end from 115 mm up to the nominal 125 mm, perfect for dialing in a precise end position during machine commissioning.

This 32 mm bore unit runs at 30-800 mm/s with a PT1/8 port and NBR seals. A stop screw on the back rod sets the stroke range and must be locked after positioning. It includes a magnet for CMSE or DMSE sensors and uses field-adjustable air cushions at both ends to decelerate the load smoothly.

Airtac SEJ Adjustable Cylinder SEJ32X125-10SN Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-10SN
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window10 mm (115–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 10mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-10SN

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-10Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-10SN Is Used

tune

Sensor Bracket Calibration

Use the 345 N both-way force and 10 mm retract dial to micro-adjust a sensor bracket testing jig into the exact 115-125 mm sensing distance without machining new spacers.

swap_horiz

PCB Conveyor Changeover

Switch a stopper arm between different board widths by turning the back-rod stop screw, leveraging the equal push and pull force to halt delicate panels cleanly.

precision_manufacturing

Small Part Pick-and-Place

Trial position a 32 mm bore gripper over varying component heights, dialing the stroke end precisely while the double-rod design prevents rotational drift.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-10SN the Right Cylinder?

Verify the 10 mm adjustment window covers your required 115-125 mm range. If you need less force, the smaller SEJ25 is not standard, so this 32 mm bore is the baseline; if you need more force, step up to the SEJ40 bore which provides 528 N both ways at 0.5 MPa. If your end position never changes after setup, a fixed-stroke SED cylinder is sufficient. Remember that the air cushion and stop screw only set the mechanical end and decelerate the load; they do not hold position on air loss, so use an external rod lock for fail-safe holding. At 125 mm stroke, side loads are minimal, but always guide the load externally for optimal seal life.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (10mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 10mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-10SN FAQ

A mechanical stop screw on the rear rod lets you dial the retract stroke over a 10 mm window. The effective stroke range is 115 mm to 125 mm. You set the exact end position on the machine and lock the screw in place.

Because it is a double-rod cylinder, the force is identical in both directions. It provides 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
