AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-20S

The AirTAC SEJ Adjustable Cylinder SEJ32X125-20S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 20mm window, so this Ø32mm unit covers an effective stroke of 105–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window20 mm
  • Effective stroke105–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-20S

The AirTAC SEJ32X125-20S is a double-acting, double-rod ISO 15552 profile cylinder. A rod exits both ends, yielding identical annulus areas so thrust is equal in both directions—about 345 N each way at 0.5 MPa. A stop screw on the back rod lets you dial the retract end up to 20 mm, setting an effective stroke range of 105-125 mm for precise on-machine positioning.

This 32 mm bore unit runs at 30-800 mm/s and includes a -S magnet for CMSE reed or DMSE electronic sensors. It features field-adjustable air cushions at both ends to tame deceleration. Because it is an extruded aluminum ISO 15552 profile, it drops into standard dimensionally interchangeable footprints without external tie rods.

Airtac SEJ Adjustable Cylinder SEJ32X125-20S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-20S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window20 mm (105–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 20mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-20S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-20Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-20S Is Used

precision_manufacturing

PCB Drill Stop Tuning

Dial in the 105-125 mm effective stroke to set a precise drill penetration depth on multi-layer PCB fabrication lines, utilizing the 345 N both-way force.

sync_alt

Packaging Changeover

Adjust the retract end on the fly to accommodate different carton heights during format changeovers without swapping out the entire cylinder hardware.

science

Lab Dispenser Positioning

Fine-tune the exact retraction point for a liquid dispensing nozzle in analytical equipment, relying on the equal push and pull forces for consistent fluid metering.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-20S the Right Cylinder?

Verify the 20 mm adjustment window covers your required end-position range; here you can tune the retract stroke anywhere from 105 to 125 mm. If you need less force, the next bore down is not available in this series, but if you need more thrust, step up to the 40 mm bore which provides 528 N both ways at 0.5 MPa. If your stroke never changes after commissioning, a fixed-stroke SED saves cost.

When matching an ISO 15552 replacement, confirm the 125 mm stroke, 20 mm window, PT1/8 port, and your mounting choice (Basic, FA, LB, TC, FTC, TCM1, or TCM2). The air cushion is adjustable, not a lock; this cylinder will not hold position on air loss. For fail-safe holding, specify an external rod lock.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (20mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 20mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-20S FAQ

The stop screw on the back rod allows you to mechanically shorten the retract stroke by up to 20 mm. This gives an effective stroke range of 105 to 125 mm, which you lock in place after setting your exact end position.

Because the rod exits both ends, the annulus area is identical in both directions. It outputs 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa, ensuring equal thrust extending and retracting.
