AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X125-30S

The AirTAC SEJ Adjustable Cylinder SEJ32X125-30S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 30mm window, so this Ø32mm unit covers an effective stroke of 95–125mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke125 mm
  • Adjust window30 mm
  • Effective stroke95–125 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X125-30S

The AirTAC SEJ32X125-30S is a double-acting, double-rod ISO 15552 profile cylinder with a 30 mm adjustable stroke window. A rod exits both ends, meaning the annulus area is identical in both directions. This provides an equal drive force of 345 N each way at 0.5 MPa, ensuring perfectly balanced extend and retract movements.

You can dial the retract end position from 95 mm up to the nominal 125 mm using a mechanical stop screw on the back rod. The extruded aluminum barrel has no external tie rods, and the built-in magnet supports CMSE reed and DMSE electronic sensors for position feedback. Adjustable air cushions at both ends absorb kinetic energy near stroke end.

Airtac SEJ Adjustable Cylinder SEJ32X125-30S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X125-30S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke125 mm
Adjustment window30 mm (95–125 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 30mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X125-30S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×125Nominal stroke length in mm.
-30Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X125-30S Is Used

precision_manufacturing

PCB Drill Depth Stop

Dial the 30 mm window to set precise 95-125 mm drill strokes. The equal 345 N both-way force ensures stable retraction without drift.

swap_horiz

Packaging Changeover

Quickly adjust the retract end to accommodate different carton heights.

tune

Small Part Press Fit

Fine-tune the insertion depth on the machine. The 70 kgf max thrust handles light assembly while the stop screw locks the final position.

Is the Airtac SEJ Adjustable Cylinder SEJ32X125-30S the Right Cylinder?

Verify the 30 mm adjustment window covers your required end-position range. If you need less force, there is no smaller SEJ bore, so you must rely on pressure regulation. If your application demands more thrust, stepping up to the 40 mm bore yields 528 N both ways at 0.5 MPa. If your position never changes after commissioning, a fixed-stroke SED cylinder is sufficient.

For a direct ISO 15552 replacement, match the 125 mm stroke, 30 mm window, PT1/8 port, and your mounting choice from Basic, FA, LB, TC, FTC, TCM1, or TCM2. Remember that the air cushion and stop screw decelerate the load but do not hold position on air loss; for fail-safe holding, specify an external rod lock.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (30mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 30mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X125-30S FAQ

A stop screw on the rear rod lets you mechanically shorten the retract stroke by up to 30 mm. For a 125 mm nominal stroke, the effective retract range is 95-125 mm. You lock the screw after setting your desired end position.

Because it is a double-rod cylinder, force is equal in both directions. It provides 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
